Diagram image 1 of 2

PC3000-6E S/N 06262

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6E S/N 06262

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	947 947 40	Retainer Engine	1	InternBDB: HALTER MOTOR-KK II PC 3000- 6E \| InternKon: 939 075 40 / 1
?	948 824 40	Harness Engine stop - Heather	1	InternBDB: KABELB MOTSTILLSTAND-HEIZ PC 3000- 6E \| InternKon: 939 075 40 / 2
?	948 825 40	Harness LT-Switchbox - Engine	1	InternBDB: KABELB NS-SCHALTSCHR-MOT PC 3000- 6E \| InternKon: 939 075 40 / 3
?	948 826 40	Harness Control Condenser	1	InternBDB: KABELB UEBERWACH KONDENS PC 3000- 6E \| InternKon: 939 075 40 / 4
?	948 800 40	Cable Fixing	1	InternBDB: KABELBEFESTIGUNG KPL PC 3000- 6E \| InternKon: 939 075 40 / 5
?	938 340 40	Plate	7	InternBDB: KABELBEFESTIGUNG KPL PC 3000- 6 \| InternKon: 939 075 40 / 6
?	948 813 40	Flange Plate	1	InternBDB: FLANSCHPLATTE F ROXTEC PC 3000- 6E \| InternKon: 939 075 40 / 7
?	517 122 98	Lock washer	14	InternBDB: SG-SHB 10 STZN WN 65593840 \| InternKon: 939 075 40 / 8
?	307 775 99	Bolt	14	InternBDB: 6KTSHR M10 X 20 8.8 DIN 00933 \| InternKon: 939 075 40 / 9
?	0443453211	Clip NW 32	10	InternBDB: CLIP KES 04434 \| InternKon: 939 075 40 / 10
?	340 465 99	Washer	33	InternBDB: SHB B 10,5 140HV DIN 00125 \| InternKon: 939 075 40 / 11
?	507 037 98	Nut	28	InternBDB: 6KTMU M10 8 DIN 00985 \| InternKon: 939 075 40 / 12
?	0443451510	Clip NW 15	10	InternBDB: CLIP 77 KES 04434 \| InternKon: 939 075 40 / 13
?	0443451210	Clip NW 12	10	InternBDB: CLIP 77 KES 04434 \| InternKon: 939 075 40 / 14
?	308 576 99	Bolt	5	InternBDB: 6KTSHR M10X 45 8.8 DIN 00931 \| InternKon: 939 075 40 / 15
?	948 815 40	Seal	1	InternBDB: NBR 80 \| InternKon: 939 075 40 / 16
?	907 477 40	Cable union DN 12	1	InternBDB: VERSHR NW 12 GERADE BVNV-M162 \| InternKon: 948 824 40 / 1
?	655 650 40	Cable protection hose DN 12	-2	InternBDB: SCHUTZSHL NW 12 VCST-12B \| InternKon: 948 824 40 / 2
?	907 890 40	Cable 1,5 sqmm black	-2	InternBDB: KENPUR-LITZE 1,5MM2 SCHWARZ 090150SW \| InternKon: 948 824 40 / 3
?	655 873 40	Cable 1,5 sqmm blue	-2	InternBDB: KENPUR-LITZE 1,5MM2 BLAU 090150BL \| InternKon: 948 824 40 / 4
?	655 079 40	Cable 1.5 sqmm green/yellow	-2	InternBDB: KENPUR-LITZE 1,5MM2 GRUEN/GELB 090150GG \| InternKon: 948 824 40 / 5
?	635 042 40	Wire end ferrule 1,5	6	InternBDB: ADERENDHUELSE D=1,5 203124-20 CE015 U \| InternKon: 948 824 40 / 8
?	907 479 40	Cable union DN 29	1	InternBDB: VERSHR NW 29 GERADE BVNV-M329 \| InternKon: 948 825 40 / 1
?	655 696 40	Cable protection hose DN 29	-2	InternBDB: SCHUTZSHL NW 29 VCSG-29B \| InternKon: 948 825 40 / 2
?	056 070 40	Cable sleeve 1,0-1,5	64	InternBDB: KABELHUELSE 1,0-1,5 \| InternKon: 948 825 40 / 3
?	940 169 40	Cable 4x 1 sqmm	-2	InternBDB: KENPUR 600C 4X 1,0MM2 CE \| InternKon: 948 825 40 / 4
?	655 628 40	T-Distributor DN 10	1	InternBDB: T-VERTEILER NW 10 BFTL-101010TTT \| InternKon: 948 826 40 / 1
?	655 649 40	Cable protection hose DN 10	-2	InternBDB: SCHUTZSHL NW 10 VCST-10B \| InternKon: 948 826 40 / 2
?	655 080 40	Cable 1,5 sqmm red	-2	InternBDB: KENPUR-LITZE 1,5MM2 ROT 090150RT \| InternKon: 948 826 40 / 3
?	635 042 40	Wire end ferrule 1,5	6	InternBDB: ADERENDHUELSE D=1,5 203124-20 CE015 U \| InternKon: 948 826 40 / 6
?	907 476 40	Cable union DN 10	2	InternBDB: VERSHR NW 10 GERADE BVNV-M120 \| InternKon: 948 826 40 / 7
?	256 514 40	Plate	3	InternBDB: SCHILD 15X30X1,5 ALU \| InternKon: 948 826 40 / 4
?	056 292 40	Cable strap	3	InternBDB: KABELBAND TY 23 M \| InternKon: 948 826 40 / 5

Komatsu PC3000-6E S/N 06262 parts catalog PDF

CABLES - ENGINE (255-2184) in PC3000-6E S/N 06262. Diagram image and parts list.
