01 |
947 947 40
|
Retainer Engine |
1 |
InternBDB: HALTER MOTOR-KK II PC 3000- 6E | InternKon: 939 075 40 / 1
|
|
|
|
02 |
948 824 40
|
Harness Engine stop - Heather |
1 |
InternBDB: KABELB MOTSTILLSTAND-HEIZ PC 3000- 6E | InternKon: 939 075 40 / 2
|
|
|
|
03 |
948 825 40
|
Harness LT-Switchbox - Engine |
1 |
InternBDB: KABELB NS-SCHALTSCHR-MOT PC 3000- 6E | InternKon: 939 075 40 / 3
|
|
|
|
04 |
948 826 40
|
Harness Control Condenser |
1 |
InternBDB: KABELB UEBERWACH KONDENS PC 3000- 6E | InternKon: 939 075 40 / 4
|
|
|
|
05 |
948 800 40
|
Cable Fixing |
1 |
InternBDB: KABELBEFESTIGUNG KPL PC 3000- 6E | InternKon: 939 075 40 / 5
|
|
|
|
06 |
938 340 40
|
Plate |
7 |
InternBDB: KABELBEFESTIGUNG KPL PC 3000- 6 | InternKon: 939 075 40 / 6
|
|
|
|
07 |
948 813 40
|
Flange Plate |
1 |
InternBDB: FLANSCHPLATTE F ROXTEC PC 3000- 6E | InternKon: 939 075 40 / 7
|
|
|
|
08 |
517 122 98
|
Lock washer |
14 |
InternBDB: SG-SHB 10 STZN WN 65593840 | InternKon: 939 075 40 / 8
|
|
|
|
09 |
307 775 99
|
Bolt |
14 |
InternBDB: 6KTSHR M10 X 20 8.8 DIN 00933 | InternKon: 939 075 40 / 9
|
|
|
|
10 |
0443453211
|
Clip NW 32 |
10 |
InternBDB: CLIP KES 04434 | InternKon: 939 075 40 / 10
|
|
|
|
11 |
340 465 99
|
Washer |
33 |
InternBDB: SHB B 10,5 140HV DIN 00125 | InternKon: 939 075 40 / 11
|
|
|
|
12 |
507 037 98
|
Nut |
28 |
InternBDB: 6KTMU M10 8 DIN 00985 | InternKon: 939 075 40 / 12
|
|
|
|
13 |
0443451510
|
Clip NW 15 |
10 |
InternBDB: CLIP 77 KES 04434 | InternKon: 939 075 40 / 13
|
|
|
|
14 |
0443451210
|
Clip NW 12 |
10 |
InternBDB: CLIP 77 KES 04434 | InternKon: 939 075 40 / 14
|
|
|
|
15 |
308 576 99
|
Bolt |
5 |
InternBDB: 6KTSHR M10X 45 8.8 DIN 00931 | InternKon: 939 075 40 / 15
|
|
|
|
16 |
948 815 40
|
Seal |
1 |
InternBDB: NBR 80 | InternKon: 939 075 40 / 16
|
|
|
|
17 |
907 477 40
|
Cable union DN 12 |
1 |
InternBDB: VERSHR NW 12 GERADE BVNV-M162 | InternKon: 948 824 40 / 1
|
|
|
|
18 |
655 650 40
|
Cable protection hose DN 12 |
-2 |
InternBDB: SCHUTZSHL NW 12 VCST-12B | InternKon: 948 824 40 / 2
|
|
|
|
19 |
907 890 40
|
Cable 1,5 sqmm black |
-2 |
InternBDB: KENPUR-LITZE 1,5MM2 SCHWARZ 090150SW | InternKon: 948 824 40 / 3
|
|
|
|
20 |
655 873 40
|
Cable 1,5 sqmm blue |
-2 |
InternBDB: KENPUR-LITZE 1,5MM2 BLAU 090150BL | InternKon: 948 824 40 / 4
|
|
|
|
21 |
655 079 40
|
Cable 1.5 sqmm green/yellow |
-2 |
InternBDB: KENPUR-LITZE 1,5MM2 GRUEN/GELB 090150GG | InternKon: 948 824 40 / 5
|
|
|
|
22 |
635 042 40
|
Wire end ferrule 1,5 |
6 |
InternBDB: ADERENDHUELSE D=1,5 203124-20 CE015 U | InternKon: 948 824 40 / 8
|
|
|
|
24 |
907 479 40
|
Cable union DN 29 |
1 |
InternBDB: VERSHR NW 29 GERADE BVNV-M329 | InternKon: 948 825 40 / 1
|
|
|
|
25 |
655 696 40
|
Cable protection hose DN 29 |
-2 |
InternBDB: SCHUTZSHL NW 29 VCSG-29B | InternKon: 948 825 40 / 2
|
|
|
|
26 |
056 070 40
|
Cable sleeve 1,0-1,5 |
64 |
InternBDB: KABELHUELSE 1,0-1,5 | InternKon: 948 825 40 / 3
|
|
|
|
27 |
940 169 40
|
Cable 4x 1 sqmm |
-2 |
InternBDB: KENPUR 600C 4X 1,0MM2 CE | InternKon: 948 825 40 / 4
|
|
|
|
29 |
655 628 40
|
T-Distributor DN 10 |
1 |
InternBDB: T-VERTEILER NW 10 BFTL-101010TTT | InternKon: 948 826 40 / 1
|
|
|
|
30 |
655 649 40
|
Cable protection hose DN 10 |
-2 |
InternBDB: SCHUTZSHL NW 10 VCST-10B | InternKon: 948 826 40 / 2
|
|
|
|
31 |
655 080 40
|
Cable 1,5 sqmm red |
-2 |
InternBDB: KENPUR-LITZE 1,5MM2 ROT 090150RT | InternKon: 948 826 40 / 3
|
|
|
|
32 |
635 042 40
|
Wire end ferrule 1,5 |
6 |
InternBDB: ADERENDHUELSE D=1,5 203124-20 CE015 U | InternKon: 948 826 40 / 6
|
|
|
|
33 |
907 476 40
|
Cable union DN 10 |
2 |
InternBDB: VERSHR NW 10 GERADE BVNV-M120 | InternKon: 948 826 40 / 7
|
|
|
|
34 |
256 514 40
|
Plate |
3 |
InternBDB: SCHILD 15X30X1,5 ALU | InternKon: 948 826 40 / 4
|
|
|
|
35 |
056 292 40
|
Cable strap |
3 |
InternBDB: KABELBAND TY 23 M | InternKon: 948 826 40 / 5
|
|
