01 |
953 178 40
|
Capacitor aasy. |
2 |
|
|
|
|
02 |
921 221 40
|
Plate |
2 |
|
|
|
|
04 |
896 741 40
|
Shock absorber |
8 |
|
|
|
|
05 |
308 638 99
|
Bolt |
8 |
|
|
|
|
06 |
510 733 98
|
Resilient sleeve |
8 |
|
|
|
|
07 |
308 610 99
|
Bolt |
32 |
|
|
|
|
08 |
510 744 98
|
Resilient sleeve |
32 |
|
|
|
|
09 |
316 216 99
|
Washer |
32 |
|
|
|
|
10 |
308 554 99
|
Bolt |
16 |
|
|
|
|
11 |
334 599 99
|
Nut |
16 |
|
|
|
|
12 |
340 464 99
|
Washer |
32 |
|
|
|
|
13 |
332 334 99
|
Nut |
32 |
|
|
|
|
20 |
953 077 40
|
Cable harness capacitor / movement signal |
1 |
|
|
|
|
21 |
655 651 40
|
Cable protection hose DN 17 |
-2 |
|
|
|
|
22 |
655 649 40
|
Cable protection hose DN 10 |
-2 |
|
|
|
|
23 |
907 975 40
|
Fitting 29"/DN17 |
1 |
|
|
|
|
24 |
940 471 40
|
Fitting M16/DN10 |
5 |
|
|
|
|
25 |
655 629 40
|
T-Distributor DN 17 |
2 |
|
|
|
|
26 |
655 632 40
|
Pipe adapter DN 17/10 |
5 |
|
|
|
|
27 |
655 628 40
|
T-Distributor DN 10 |
3 |
|
|
|
|
28 |
655 633 40
|
Pipe adapter DN 17/12 |
1 |
|
|
|
|
29 |
941 840 40
|
Protective hose DN 12 |
-2 |
|
|
|
|
30 |
952 675 40
|
Plug assy. with rubber grommet 2 pole |
1 |
|
|
|
|
31 |
940 461 40
|
Insulating tube B5x0,6 |
-2 |
|
|
|
|
32 |
907 934 40
|
Pin contact |
10 |
|
|
|
|
33 |
0819100770
|
Sealing plug |
4 |
|
|
|
|
34 |
950 131 40
|
Protection cap |
1 |
|
|
|
|
35 |
635 042 40
|
Wire end ferrule 1,5 |
14 |
|
|
|
|
36 |
940 271 40
|
Cable union DN 10 |
1 |
|
|
|
|
37 |
515 213 40
|
Cable 1,0 |
-2 |
|
|
|
|
38 |
174 411 40
|
Cable strap |
22 |
|
|
|
|
39 |
941 777 40
|
Plate |
11 |
|
|
|
|
40 |
950 136 40
|
Plug |
1 |
|
|
|
|
52 |
958 561 40
|
Harness - winding temperature - motor 1 connection front side |
1 |
|
|
|
|
53 |
958 564 40
|
Harness - heater - motor 1 connection front side |
1 |
|
|
|
|
54 |
958 566 40
|
Harness - heater - motor 2 connection front side |
1 |
|
|
|
|
55 |
958 567 40
|
Harness - winding temperature - motor 2 connection front side |
1 |
|
|
|
|
61 |
950 110 40
|
Plug |
2 |
|
|
|
|
62 |
0819105320
|
Pin contact |
40 |
|
|
|
|
63 |
940 852 40
|
Plug |
6 |
|
|
|
|
64 |
950 132 40
|
Protection cap |
2 |
|
|
|
|
65 |
500 090 98
|
Wire end ferrule 0,75-6 |
40 |
|
|
|
|
68 |
940 169 40
|
Cable 4x1 |
-2 |
|
|
|
|
69 |
907 981 40
|
Fitting 35"/DN29 |
2 |
|
|
|
|
70 |
655 696 40
|
Cable protection hose DN 29 |
-2 |
|
|
|
|
71 |
907 947 40
|
Connector distributor DN 29/23 |
2 |
|
|
|
|
72 |
655 634 40
|
Pipe adapter DN 23/17 |
2 |
|
|
|
|
73 |
655 652 40
|
Cable protection hose DN 23 |
-2 |
|
|
|
|
76 |
655 627 40
|
Distributor DN 23/17 |
2 |
|
|
|
|
78 |
950 207 40
|
End grommet |
2 |
|
|
|
|
79 |
950 209 40
|
End grommet |
4 |
|
|
|
|
81 |
907 890 40
|
Cable 1,5sw |
-2 |
|
|
|
|
82 |
655 873 40
|
Cable 1,5 |
-2 |
|
|
|
|
83 |
655 079 40
|
Cable 1.5 gr/ge |
-2 |
|
|
|
|
86 |
655 621 40
|
Cable union DN 10 |
2 |
|
|
|
|
89 |
950 207 40
|
End grommet |
2 |
|
|
|
|
91 |
955 680 40
|
Ground cable Cover-Box M1 |
-2 |
|
|
|
|
92 |
955 681 40
|
Ground cable Terminal-Base M1 |
-2 |
|
|
|
|
93 |
955 682 40
|
Ground cable Terminal-Base-Motor M1 |
-2 |
|
|
|
|
94 |
955 683 40
|
Ground cable Motor-Motorframe M1 |
-2 |
|
|
|
|
95 |
955 684 40
|
Ground cable Capacitor-Base M1 |
-2 |
|
|
|
|
96 |
955 685 40
|
Ground cable Capacitor-Frame-Base M1 |
-2 |
|
|
|
|
97 |
955 687 40
|
Ground cable Cover-Box M2 |
-2 |
|
|
|
|
98 |
955 688 40
|
Ground cable Terminal-Base M2 |
-2 |
|
|
|
|
99 |
955 689 40
|
Ground cable Terminal-Base-Motor M2 |
-2 |
|
|
|
|
100 |
955 690 40
|
Ground cable Motor-Motorframe M2 |
-2 |
|
|
|
|
101 |
955 691 40
|
Ground cable Capacitor-Base M2 |
-2 |
|
|
|
|
102 |
955 692 40
|
Ground cable Capacitor-Frame-Base M2 |
-2 |
|
|
|
|
103 |
056 076 40
|
Protection cap |
-2 |
|
|
|
|
104 |
654 425 40
|
Cable lug 50/12 |
-2 |
|
|
|
|
105 |
517 392 98
|
Cable 50,0 |
-2 |
|
|
|
|
106 |
654 425 40
|
Cable lug 50/10 |
-2 |
|
|
