01 |
|
Drive gear box |
2 |
InternBDB: 898 108 40 | InternKon: TT 936 608 40 / 6
|
991-0453 |
|
|
02 |
675 899 40
|
Drive sprocket |
2 |
InternKon: TT 936 608 40 / 5
|
|
|
|
02 |
886 297 40
|
Drive sprocket, oversize |
2 |
|
|
|
|
03 |
925 698 40
|
Track frame r.h. |
1 |
InternBDB: SK 925 660 40 | InternKon: TT 936 608 40 / 1
|
|
|
|
04 |
927 111 40
|
Track frame l.h. |
1 |
InternBDB: SK 927 112 40 | InternKon: TT 936 608 40 / 1
|
|
|
|
05 |
308 355 99
|
Bolt (standard) |
60 |
InternBDB: M36x180 DIN00931 | InternKon: TT 936 608 40 / 14
|
|
|
|
05 |
511 818 98
|
Bolt (cold weather design) |
60 |
InternBDB: 6KTSHR M36X 180 10.9 KALTZ DIN 00931 | InternKon: TT 936 608 40 / 14
|
|
|
|
06 |
255 056 40
|
Washer |
216 |
InternBDB: 37 DIN06916 | InternKon: TT 936 608 40 / 15
|
|
|
|
07 |
510 512 98
|
Bolt (standard) |
48 |
InternBDB: M36x170 DIN00931 | InternKon: TT 936 608 40 / 17
|
|
|
|
07 |
510 514 98
|
Bolt (cold weather design) |
48 |
InternBDB: 6KTSHR M36X 170 10.9 KALTZ DIN 00931 | InternKon: TT 936 608 40 / 17
|
|
|
|
08 |
332 369 99
|
Nut (standard) |
108 |
InternBDB: M 36 DIN00934 | InternKon: TT 936 608 40 / 16
|
|
|
|
08 |
501 124 98
|
Nut (cold weather design) |
108 |
InternBDB: 6KTMU M 36 10 KALTZ DIN 00934 | InternKon: TT 936 608 40 / 16
|
|
|
|
10 |
|
Drive motor |
2 |
InternBDB: 654 891 40 | InternKon: 927 720 40 / 1
|
991-0080 |
|
|
11 |
307 615 99
|
Bolt |
12 |
InternBDB: M20x60 DIN00933 | InternKon: 927 720 40 / 2
|
|
|
|
12 |
316 212 99
|
Washer |
16 |
InternBDB: 21 DIN06916 | InternKon: 927 720 40 / 3
|
|
|
|
13 |
927 719 40
|
Drive motor protection |
2 |
InternKon: 927 720 40 / 4
|
|
|
|
14 |
308 416 99
|
Bolt |
4 |
InternBDB: M20x70 DIN00931 | InternKon: 927 720 40 / 5
|
|
|
|
15 |
897 637 40
|
Drive gear box protection |
2 |
InternKon: 927 724 40 / 1
|
|
|
|
16 |
307 824 99
|
Bolt |
34 |
InternBDB: M16 x 40 DIN00933 | InternKon: 927 724 40 / 2
|
|
|
|
17 |
307 819 99
|
Bolt |
2 |
InternBDB: M16 x 20 DIN00933 | InternKon: 927 724 40 / 3
|
|
|
|
21 |
621 626 40
|
Sleeve |
4 |
InternKon: 936 610 40 / 6
|
|
|
|
22 |
323 460 40
|
Bleeder valve |
4 |
InternKon: 936 610 40 / 7
|
|
|
|
23 |
339 907 99
|
Seal ring |
4 |
InternBDB: A 22x27 DIN07603 | InternKon: 936 610 40 / 8
|
|
|
|
24 |
374 408 99
|
Union |
8 |
InternBDB: SDS-L18xM22x1,5-Type E ISO08434 | InternKon: 936 610 40 / 9
|
|
|
|
25 |
576 403 40
|
Union |
8 |
InternBDB: RED 18/15-PL/OMD | InternKon: 936 610 40 / 14
|
|
|
|
26 |
517 719 98
|
Hose assy. DN 12x3000 |
2 |
InternBDB: 240 DOL 15 DOL 15 90 | InternKon: 936 610 40 / 13
|
|
|
|
27 |
371 856 99
|
Union |
2 |
InternBDB: 18-L / 011 638 99 | InternKon: 936 610 40 / 39
|
|
|
|
28 |
517 718 98
|
Hose assy. DN 12x2750 |
2 |
InternBDB: 240 DOL 15 DOL 15 | InternKon: 936 610 40 / 48
|
|
|
|
29 |
516 176 98
|
Union |
2 |
InternBDB: SWRT-L18 ISO084334-4 | InternKon: 936 610 40 / 49
|
|
|
|
30 |
898 115 40
|
Driving performance meter |
1 |
InternBDB: Deuta Werke | InternKon: 927 701 40 / 42
|
|
|
|
31 |
307 754 99
|
Bolt |
4 |
InternBDB: M8x25 8.8 DIN00933 | InternKon: 927 701 40 / 43
|
|
|
|
35 |
927 721 40
|
Drive motor protection, lower |
2 |
InternKon: 946 610 40 / 1
|
|
|
|
36 |
255 056 40
|
Washer |
18 |
InternBDB: 37 DIN06916 | InternKon: 946 610 40 / 2
|
|
|
|
37 |
515 237 98
|
Bolt |
18 |
InternBDB: M 36x295 10 DIN00934 | InternKon: 946 610 40 / 3
|
|
|
|
37 |
515 238 98
|
Bolt (Cold weather design) |
18 |
InternBDB: 6KTSHR M36X 295 10.9 KALTZ WN 34192140 | InternKon: 946 610 40 / 3
|
|
|
|
38 |
332 369 99
|
Nut |
18 |
InternBDB: M 36 10 DIN00934 | InternKon: 946 610 40 / 4
|
|
