PC3000-6 S/N 46174

Komatsu parts book diagram for PC3000-6 S/N 46174: TOP ROLLER

01 02 03 04 04 05 05 06 06 07 08 09 09 10 11

	#	Part Number	Partname	Quantity	Options	Reference
	01	429 230 40	Top roller	1	InternKon: 585-3110/03 / 674 025 40 / 01
	02	429 256 40	Support	1	InternKon: 429 230 40 / 2
	03	429 231 40	Pin	1	InternKon: 429 256 40 / 1
	04	345 150 99	Dowel pin	2	InternBDB: 16x90 /1481 \| InternKon: 429 230 40 / 4
	05	461 628 40	Lifetime seal	2	InternBDB: Gцtze 7690 H-06 \| InternKon: 429 230 40 / 5
	06	506 595 98	O-ring	2	InternBDB: 45x5,3 N NB 70 /3771 \| InternKon: 429 230 40 / 6
	07	313 484 99	Plug	1	InternBDB: M26x1,5 /906 \| InternKon: 429 230 40 / 7
	08	429 217 40	Top roller with freeze-in bushing	1	InternKon: 429 230 40 / 1
	09	429 216 40	Freeze-in bushing	2	InternBDB: 69/53x50 \| InternKon: 429 217 40 / 2
	10	308 886 99	Bolt	4	InternBDB: M 24 x 120 / 931 \| InternKon: 674 025 40 / 2
	11	316 213 40	Scheibe	4	InternBDB: 25 / 6916 \| InternKon: 674 025 40 / 3

Komatsu PC3000-6 S/N 46174 parts catalog PDF

TOP ROLLER (585-3127a) in PC3000-6 S/N 46174. Diagram image and parts list.
