PC3000-6 S/N 46174

Komatsu parts book diagram for PC3000-6 S/N 46174: CARBODY

01 02 02 03 04 05 05 06 06 06 07 08 08 09 10 11 12 13 14 15 16 17

	#	Part Number	Partname	Quantity	Options	Reference
	01		Rotary joint	1	InternBDB: 659 008 40 / 934 623 40 (TT) \| InternKon: 936 610 40 / 2	485-3155a
	02	308 321 99	Bolt	12	InternBDB: M16x90 / DIN 931 10.9 \| InternKon: 936 610 40 / 52
	03	510 733 98	Resilient sleeve	8	InternBDB: 17/30x50 /341 948 40 \| InternKon: 936 610 40 / 66
	04	927 801 40	Carbody	1	InternBDB: MB SK 927 800 40 \| InternKon: 936 610 40 / 1
	05	517 588 98	Bolt (standard)	72	InternBDB: M48x240 WN 341 920 40 10.9 \| InternKon: 936 610 40 / 24
	05	517 927 98	Bolt (cold weather design)	72	InternBDB: 6KTSHR M48X 240 10.9 KALTZ WN 34192140 \| InternKon: 936 610 40 / 24
	06	517 587 98	Resilient sleeve	76	InternBDB: 50/85x110 WN 341 948 40 \| InternKon: 936 610 40 / 25
	07	928 477 40	Test bolt (standard)	4	InternBDB: TL /M48x240 \| InternKon: 936 610 40 / 70
	07	936 612 40	Test bolt (cold weather design)	4	InternBDB: MESSSCHRAUBE M48X240 TT \| InternKon: 936 610 40 / 70
	08	307 777 99	Bolt	12	InternBDB: M10x25 / DIN 933 \| InternKon: 936 610 40 / 69
	09	928 476 40	Test equipment assy.	1	InternKon: 936 610 40 / 67
	10	929 338 40	Grease chute	2	InternKon: 936 610 40 / 91
	11	507 037 98	Nut	4	InternBDB: M 10 / DIN 985 \| InternKon: 936 610 40 / 93
	12	915 667 40	Plate	4	InternKon: 936 610 40 / 92
	13	887 386 40	Cam	1	InternKon: 936 610 40 / 11
	14	928 475 40	Angle	1	InternKon: 928 476 40 / 1
	15	092 706 40	Micrometer	1	InternBDB: Hahn u. Kolb Typ 330 750/0 DIN 878 \| InternKon: 928 476 40 / 2
	16	477 172 40	Test insert	1	InternBDB: Hahn u. Kolb 33149188 \| InternKon: 928 476 40 / 4
	17	502 515 98	Rim screw	1	InternBDB: M5x16 / DIN 464 \| InternKon: 928 476 40 / 3

Komatsu PC3000-6 S/N 46174 parts catalog PDF

CARBODY (485-3152) in PC3000-6 S/N 46174. Diagram image and parts list.
