PC3000-6 S/N 46174

Komatsu parts book diagram for PC3000-6 S/N 46174: PIN, BOOM - COUNTERWEIGHT

01 02 03 04 05 05 06 07 08 08 08 08 10 11 12 14 14

	#	Part Number	Partname	Quantity	Options	Reference
	01	931 700 40	Superstructure	1	InternKon: 934 238 40 / 1
	02	934 000 40	Counterweight	1	InternKon: 934 238 40 / 17
	03	480 649 40	Pin	2	InternKon: 934 238 40 / 24
	04	480 648 40	Pin	2	InternKon: 934 238 40 / 23
	05	887 374 40	Axle stirrup	4	InternKon: 934 238 40 / 25
	06	506 884 98	Bolt (standard)	12	InternBDB: 6KTSHR M42X 550 10.9 DIN 00931 \| InternKon: 934 238 40 / 36
	06	517 877 98	Bolt (cold weather design)	12	InternBDB: 6KTSHR M42X 550 10.9 KALTZ DIN 00931 \| InternKon: 934 238 40 / 36
	07	501 716 98	Washer	12	InternBDB: 43 / 6916 \| InternKon: 934 238 40 / 37
	08	480 657 40	Bushing	10	InternKon: 934 238 40 / 22
	10	927 200 40	Platform	1	InternKon: 934 238 40 / 19
	11	511 342 98	Bolt	12	InternBDB: M 27x130 / 931 \| InternKon: 934 238 40 / 39
	12	515 670 98	Resilient sleeve	12	InternBDB: 28/50x70 / 341 948 40 \| InternKon: 934 238 40 / 40
	14	308 870 99	Bolt (standard)	8	InternBDB: 6KTSHR M30X 90 10.9 DIN 00931 \| InternKon: 934 238 40 / 46
	14	502 578 98	Bolt (cold weather design)	8	InternBDB: 6KTSHR M30X 90 10.9 KALTZ DIN 00931 \| InternKon: 934 238 40 / 46

Komatsu PC3000-6 S/N 46174 parts catalog PDF

PIN, BOOM - COUNTERWEIGHT (485-1017a) in PC3000-6 S/N 46174. Diagram image and parts list.
