02 |
927 227 40
|
Post 1 |
1 |
InternKon: 930 553 40 / 1
|
|
|
|
03 |
927 229 40
|
Post 2 |
1 |
InternKon: 930 553 40 / 2
|
|
|
|
04 |
930 571 40
|
Post 3 |
1 |
InternKon: 930 553 40 / 3
|
|
|
|
05 |
930 501 40
|
Post 4 |
1 |
InternKon: 930 553 40 / 7
|
|
|
|
06 |
929 114 40
|
Post 5 |
1 |
InternKon: 930 553 40 / 5
|
|
|
|
07 |
930 555 40
|
Post 6 |
1 |
InternKon: 930 553 40 / 6
|
|
|
|
08 |
891 714 40
|
Post 7 |
1 |
InternKon: 930 553 40 / 4
|
|
|
|
09 |
930 554 40
|
Wall |
1 |
InternKon: 930 553 40 / 9
|
|
|
|
10 |
930 503 40
|
Door |
1 |
InternKon: 930 553 40 / 50
|
|
|
|
11 |
906 709 40
|
Fastener with out lock pin |
2 |
InternKon: 930 553 40 / 40
|
|
|
|
12 |
340 510 99
|
Washer |
2 |
InternBDB: A17,0 140HV / DIN 125 | InternKon: 930 553 40 / 41
|
|
|
|
14 |
930 550 40
|
Wall |
1 |
InternKon: 930 553 40 / 10
|
|
|
|
15 |
927 204 40
|
Door, radiator |
1 |
InternKon: 930 553 40 / 8
|
|
|
|
16 |
927 264 40
|
Wall |
1 |
InternKon: 930 553 40 / 11
|
|
|
|
17 |
390 199 40
|
Hinge |
5 |
InternKon: 930 553 40 / 14
|
|
|
|
18 |
621 983 40
|
Hinge |
4 |
InternKon: 930 553 40 / 39
|
|
|
|
19 |
930 540 40
|
Door |
1 |
InternKon: 930 553 40 / 15
|
|
|
|
20 |
927 212 40
|
Door |
1 |
InternKon: 930 553 40 / 12
|
|
|
|
22 |
934 342 40
|
Angle |
1 |
InternKon: 930 553 40 / 23
|
|
|
|
23 |
934 343 40
|
Angle |
1 |
InternKon: 930 553 40 / 24
|
|
|
|
24 |
167 693 40
|
Flex. Header |
-2 |
InternBDB: Happich 461 0031 schwarz | InternKon: 930 553 40 / 44
|
|
|
|
26 |
510 741 98
|
Resilient sleeve |
9 |
InternKon: 930 553 40 / 16
|
|
|
|
27 |
308 608 99
|
Bolt |
9 |
InternBDB: M 12x70 /931 | InternKon: 930 553 40 / 28
|
|
|
|
28 |
510 732 98
|
Resilient sleeve |
28 |
InternKon: 930 553 40 / 18
|
|
|
|
29 |
308 885 99
|
Bolt to fig-nos. 02, 06-08 |
16 |
InternKon: 930 553 40 / 26
|
|
|
|
30 |
308 414 99
|
Bolt to fig-nos. 03, 04 + 05 |
12 |
InternKon: 930 553 40 / 19
|
|
|
|
31 |
927 230 40
|
Pipe |
2 |
InternKon: 930 553 40 / 48
|
|
|
|
32 |
307 805 99
|
Bolt |
8 |
InternBDB: M 12x35 /933 | InternKon: 930 553 40 / 47
|
|
|
|
33 |
081 282 40
|
Round buffer |
1 |
InternKon: 930 553 40 / 54
|
|
|
|
34 |
319 135 99
|
Screw |
1 |
InternBDB: M6x45 / 912 | InternKon: 930 553 40 / 55
|
|
|
|
35 |
507 025 98
|
Nut |
1 |
InternBDB: M6 / 985 | InternKon: 930 553 40 / 56
|
|
|
|
36 |
308 610 99
|
Bolt |
28 |
InternBDB: M 12x80 /931 | InternKon: 930 553 40 / 29
|
|
|
|
37 |
334 600 99
|
Nut |
36 |
InternBDB: M 12 /985 | InternKon: 930 553 40 / 31
|
|
|
|
38 |
340 467 99
|
Washer |
28 |
InternBDB: B 13 /125 | InternKon: 930 553 40 / 38
|
|
|
|
41 |
308 617 99
|
Bolt |
4 |
InternBDB: M 12x150 / 931 | InternKon: 930 553 40 / 46
|
|
|
|
42 |
307 802 99
|
Bolt |
4 |
InternBDB: M 12x25 /933 | InternKon: 930 553 40 / 51
|
|
|
|
43 |
346 498 99
|
Lock washer |
4 |
InternKon: 930 553 40 / 52
|
|
|
|
45 |
332 334 99
|
Nut |
4 |
InternBDB: M 12 / 934 | InternKon: 930 553 40 / 53
|
|
|
|
46 |
887 961 40
|
Door catch |
1 |
InternBDB: 279 | InternKon: 930 553 40 / 27
|
|
|
|
47 |
539 761 40
|
Pipe |
6 |
InternBDB: 25x4x20 | InternKon: 930 553 40 / 13
|
|
|
|
48 |
512 545 98
|
Washer |
2 |
InternBDB: 13,0 | InternKon: 930 553 40 / 32
|
|
|
|
49 |
897 656 40
|
Door catch |
1 |
InternBDB: 289 | InternKon: 930 553 40 / 17
|
|
|
|
50 |
927 224 40
|
Plate |
1 |
InternKon: 930 553 40 / 33
|
|
|
|
51 |
511 263 98
|
Thread pin |
6 |
InternBDB: PM 10x25 | InternKon: 930 553 40 / 34
|
|
|
|
52 |
507 037 98
|
Nut |
6 |
InternBDB: M 10 / 985 | InternKon: 930 553 40 / 35
|
|
|
|
53 |
507 596 98
|
Washer |
6 |
InternBDB: A 11 | InternKon: 930 553 40 / 36
|
|
|
|
54 |
440 821 40
|
Rubber |
-2 |
InternBDB: 30x30 | InternKon: 930 553 40 / 37
|
|
|
|
60 |
919 943 40
|
Roof section 1 |
1 |
InternKon: 925 752 40 / 1
|
|
|
|
61 |
925 753 40
|
Roof section 2 |
1 |
InternKon: 925 752 40 / 2
|
|
|
|
62 |
925 754 40
|
Roof section 3 |
1 |
InternKon: 925 752 40 / 3
|
|
|
|
63 |
925 755 40
|
Roof section 4 |
1 |
InternKon: 925 752 40 / 4
|
|
|
|
64 |
510 741 98
|
Resilient sleeve |
45 |
InternKon: 925 752 40 / 5
|
|
|
|
65 |
308 608 99
|
Bolt |
45 |
InternBDB: M 12x70 /931 | InternKon: 925 752 40 / 6
|
|
|
|
66 |
307 949 99
|
Bolt |
7 |
InternBDB: M 12x25 /933 | InternKon: 925 752 40 / 7
|
|
|
|
67 |
517 118 98
|
Lock washer |
7 |
InternBDB: 12 | InternKon: 925 752 40 / 8
|
|
|
|
68 |
598 248 40
|
Threaded rail |
2 |
InternKon: 925 752 40 / 9
|
|
|
|
69 |
598 250 40
|
Threaded rail |
2 |
InternKon: 925 752 40 / 10
|
|
|
|
70 |
598 249 40
|
Threaded rail |
2 |
InternKon: 925 752 40 / 11
|
|
|
|
71 |
598 240 40
|
Threaded rail |
2 |
InternKon: 925 752 40 / 12
|
|
|
|
72 |
598 239 40
|
Threaded rail |
4 |
InternKon: 925 752 40 / 13
|
|
|
|
73 |
180 894 40
|
Plug |
10 |
InternBDB: F 10 - PE Weich | InternKon: 925 752 40 / 14
|
|
|
|
80 |
919 949 40
|
Roof frame |
1 |
InternKon: 925 751 40 / 8
|
|
|
|
81 |
180 889 40
|
Plug |
4 |
InternBDB: F 211 PE Weich | InternKon: 925 751 40 / 4
|
|
|
|
85 |
308 356 99
|
Bolt |
14 |
InternBDB: M 36x200 / 931 | InternKon: 919 904 40 / 52
|
|
