01 |
927 345 40
|
Steps |
1 |
InternKon: 925 290 40 / 33
|
|
|
|
02 |
937 908 40
|
Stop |
1 |
InternBDB: ANSCHLAG PC 3000- 6 | InternKon: 925 290 40 / 41
|
|
|
|
03 |
937 905 40
|
Thread plate |
2 |
InternBDB: GEWINDEPLATTE 110X196 | InternKon: 925 290 40 / 42
|
|
|
|
04 |
500 816 98
|
Bolt |
4 |
InternBDB: 6KTSHR M12X 75 8.8 A2E DIN 00931 | InternKon: 925 290 40 / 43
|
|
|
|
05 |
510 744 98
|
Resilient sleeve |
19 |
InternBDB: 13 /25X 32 42CRMO4-TQ+T WN 34194840 | InternKon: 925 290 40 / 44
|
|
|
|
06 |
896 534 40
|
Hydraulic cylinder |
1 |
InternBDB: 80/ 40X 420 / Burnside | InternKon: 925 290 40 / 47
|
991-0462 |
|
|
07 |
517 617 98
|
Pin |
2 |
InternBDB: 40F 7X 75X 65 ST52-3 DIN 01434 | InternKon: 925 290 40 / 49
|
|
|
|
08 |
500 995 98
|
Washer |
4 |
InternBDB: B 41,0 140HV DIN 00125 | InternKon: 925 290 40 / 50
|
|
|
|
09 |
342 125 99
|
Cotter pin |
2 |
InternBDB: 8 X 71 ST33 DIN 00094 | InternKon: 925 290 40 / 51
|
|
|
|
10 |
516 603 98
|
Nut |
2 |
InternBDB: M 39 10 DIN 00985 | InternKon: 925 290 40 / 52
|
|
|
|
11 |
896 535 40
|
Silent block |
2 |
InternKon: 925 290 40 / 59
|
|
|
|
12 |
332 334 99
|
Nut |
2 |
InternBDB: M 12 8 DIN 00934 | InternKon: 925 290 40 / 60
|
|
|
|
15 |
915 339 40
|
Bearing set assy. fig-nos. 16-19 |
2 |
InternKon: 925 290 40 / 64
|
|
|
|
16 |
517 749 98
|
Dowel screw |
1 |
InternBDB: M 39x100 10.9 / DIN 609 | InternKon: 915 339 40 / 1
|
|
|
|
17 |
903 299 40
|
Distance sleeve |
2 |
InternKon: 915 339 40 / 2
|
|
|
|
18 |
360 427 99
|
Roller bearing |
1 |
InternBDB: 6308 C3 / DIN 625 | InternKon: 915 339 40 / 3
|
|
|
|
19 |
516 412 98
|
Shaft seal |
2 |
InternBDB: 6308 AV / WN 011 203 99 | InternKon: 915 339 40 / 4
|
|
|
|
25 |
517 644 98
|
Hose assy. DN 10x9200 |
1 |
InternBDB: 050 DOL 12 / DOS 12-90 | InternKon: 935 281 40 / 111
|
|
|
|
26 |
517 754 98
|
Hose assy. DN 10 x 8700 |
1 |
InternBDB: 050 DOL 12 / DOS 12 | InternKon: 935 281 40 / 112
|
|
|
|
27 |
374 434 99
|
Socket |
2 |
InternBDB: SDS-S12x M18x1,5 | InternKon: 935 281 40 / 106
|
|
