PC3000-6 S/N 46174

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	925 742 40	Header	1	InternKon: 933 854 40 / 1
?	925 744 40	Water pipe	1	InternKon: 933 854 40 / 2
?	925 747 40	Water pipe	1	InternKon: 933 854 40 / 3
?	891 735 40	Water pipe	1	InternKon: 933 854 40 / 4
?	891 728 40	Water pipe	1	InternKon: 933 854 40 / 5
?	932 710 40	Water hose l=0,29m	2	InternBDB: 307-125x290 \| InternKon: 933 854 40 / 6
?	907 090 40	Hose clip	4	InternBDB: C1-1-144x25 \| InternKon: 933 854 40 / 7
?	255 604 40	Water hose	-2	InternBDB: NW 55x6 Manke DBL 6254/11 \| InternKon: 933 854 40 / 8
?	907 580 40	Hose clip	8	InternBDB: C1-2-66x20 \| InternKon: 933 854 40 / 9
?	932 711 40	Water hose l=0,23m	2	InternBDB: 307-75x230 \| InternKon: 933 854 40 / 10
?	907 752 40	Hose clip	12	InternBDB: GBS 89/25 M8 \| InternKon: 933 854 40 / 11
?	925 746 40	Water pipe	1	InternKon: 933 854 40 / 12
?	514 730 98	Hose assy. DN 32 x 2600	1	InternBDB: 3 TE DOL 35 / 341 951 40 \| InternKon: 933 854 40 / 13
?	374 422 99	Socket	1	InternBDB: SDS-L35x M 42x2 \| InternKon: 933 854 40 / 14
?	514 731 98	Hose assy. DN 8 x 1400	1	InternBDB: 240 DOL 10 DOL 10 \| InternKon: 933 854 40 / 15
?	517 293 98	Union	2	InternBDB: GE 10-PL /1/4 NPT / OMD \| InternKon: 933 854 40 / 16
?	517 294 98	Union	1	InternBDB: GE 10-PL / 3/8 NPT /OMD \| InternKon: 933 854 40 / 17
?	514 732 98	Hose assy. DN 8 x 700	1	InternBDB: 240 DOL 10 DOL 10 90 \| InternKon: 933 854 40 / 18
?	517 585 98	Hose clip	1	InternBDB: C1-2-42x18 \| InternKon: 933 854 40 / 19
?	506 308 98	Pair of clamps	6	InternKon: 933 854 40 / 20
?	518 038 98	Pair of clamps (Cold weather design)	6	InternKon: 933 854 40 / 20
?	319 136 99	Screw	6	InternBDB: M6x50 / DIN 912 \| InternKon: 933 854 40 / 22
?	340 405 99	Washer	6	InternBDB: 6,4 / DIN 433 \| InternKon: 933 854 40 / 23
?	461 434 40	Drain cock	1	InternBDB: Roelex 1" / M26 8521/1 m. Kette \| InternKon: 933 854 40 / 24
?	896 662 40	Adapter	1	InternBDB: Aeroquip G 2216-4-6S 9/16-18-1/4-18 \| InternKon: 933 854 40 / 25
?	932 712 40	Water hose l=0,22m	2	InternBDB: 307-75x220 \| InternKon: 933 854 40 / 28
?	255 985 40	Plug	1	InternBDB: VSTI M14x1,5 ED / WN 34191340 \| InternKon: 933 854 40 / 37
?	932 713 40	Water hose l=0,19m	2	InternBDB: 307-75x190 \| InternKon: 933 854 40 / 30
?	269 742 40	Plug	1	InternBDB: 1/4" NPT / Licoln \| InternKon: 933 854 40 / 38
?	506 215 98	Pair of clamps	2	InternBDB: L-2-G-14 / DIN 3015 \| InternKon: 933 854 40 / 32
?	518 039 98	Pair of clamps (Cold weather design)	2	InternBDB: L-2-G-14 / DIN 3015 \| InternKon: 933 854 40 / 32
?	319 132 99	Screw	2	InternBDB: M6x25 / DIN 912 \| InternKon: 933 854 40 / 33
?	340 405 99	Washer	2	InternBDB: 6,4 / DIN 433 \| InternKon: 933 854 40 / 34
?	533 989 99	Weld on plate	1	InternBDB: L-AP-K-2 / DIN 3015 \| InternKon: 891 728 40 / 5
?	891 725 40	Clamp	1	InternKon: 933 857 40 / 5
?	307 780 99	Bolt	1	InternBDB: M10x35 / DIN 933 \| InternKon: 933 857 40 / 11
?	507 037 98	Nut	1	InternBDB: M 10 / DIN 985 \| InternKon: 933 857 40 / 14
?	340 465 99	Washer	1	InternBDB: B 10,5 / DIN 125 \| InternKon: 933 857 40 / 16
?	894 403 40	Plate	1	InternKon: 933 857 40 / 3
?	490 020 40	Clamp	3	InternBDB: Norma mit Konsole 2-tlg. D=133 \| InternKon: 933 857 40 / 9
?	307 754 99	Bolt	6	InternBDB: M8x25 / DIN 933 \| InternKon: 933 857 40 / 10
?	334 599 99	Nut	6	InternBDB: M 8 / DIN 985 \| InternKon: 933 857 40 / 13
?	937 903 40	Retainer	1	InternKon: 933 857 40 / 7
?	340 464 99	Washer	12	InternBDB: B 8,4 / DIN 125 \| InternKon: 933 857 40 / 20

Komatsu PC3000-6 S/N 46174 parts catalog PDF

COOLANT LINES (485-1241b) in PC3000-6 S/N 46174. Diagram image and parts list.
