COOLANT LINES | PC3000-6 S/N 46174 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	925 742 40	Header	1	InternKon: 933 854 40 / 1
02	925 744 40	Water pipe	1	InternKon: 933 854 40 / 2
03	925 747 40	Water pipe	1	InternKon: 933 854 40 / 3
04	891 735 40	Water pipe	1	InternKon: 933 854 40 / 4
05	891 728 40	Water pipe	1	InternKon: 933 854 40 / 5
06	932 710 40	Water hose l=0,29m	2	InternBDB: 307-125x290 \| InternKon: 933 854 40 / 6
07	907 090 40	Hose clip	4	InternBDB: C1-1-144x25 \| InternKon: 933 854 40 / 7
08	255 604 40	Water hose	-2	InternBDB: NW 55x6 Manke DBL 6254/11 \| InternKon: 933 854 40 / 8
09	907 580 40	Hose clip	8	InternBDB: C1-2-66x20 \| InternKon: 933 854 40 / 9
10	932 711 40	Water hose l=0,23m	2	InternBDB: 307-75x230 \| InternKon: 933 854 40 / 10
11	907 752 40	Hose clip	12	InternBDB: GBS 89/25 M8 \| InternKon: 933 854 40 / 11
12	925 746 40	Water pipe	1	InternKon: 933 854 40 / 12
13	514 730 98	Hose assy. DN 32 x 2600	1	InternBDB: 3 TE DOL 35 / 341 951 40 \| InternKon: 933 854 40 / 13
14	374 422 99	Socket	1	InternBDB: SDS-L35x M 42x2 \| InternKon: 933 854 40 / 14
15	514 731 98	Hose assy. DN 8 x 1400	1	InternBDB: 240 DOL 10 DOL 10 \| InternKon: 933 854 40 / 15
16	517 293 98	Union	2	InternBDB: GE 10-PL /1/4 NPT / OMD \| InternKon: 933 854 40 / 16
17	517 294 98	Union	1	InternBDB: GE 10-PL / 3/8 NPT /OMD \| InternKon: 933 854 40 / 17
18	514 732 98	Hose assy. DN 8 x 700	1	InternBDB: 240 DOL 10 DOL 10 90 \| InternKon: 933 854 40 / 18
19	517 585 98	Hose clip	1	InternBDB: C1-2-42x18 \| InternKon: 933 854 40 / 19
20	506 308 98	Pair of clamps	6	InternKon: 933 854 40 / 20
20	518 038 98	Pair of clamps (Cold weather design)	6	InternKon: 933 854 40 / 20
22	319 136 99	Screw	6	InternBDB: M6x50 / DIN 912 \| InternKon: 933 854 40 / 22
23	340 405 99	Washer	6	InternBDB: 6,4 / DIN 433 \| InternKon: 933 854 40 / 23
24	461 434 40	Drain cock	1	InternBDB: Roelex 1" / M26 8521/1 m. Kette \| InternKon: 933 854 40 / 24
25	896 662 40	Adapter	1	InternBDB: Aeroquip G 2216-4-6S 9/16-18-1/4-18 \| InternKon: 933 854 40 / 25
28	932 712 40	Water hose l=0,22m	2	InternBDB: 307-75x220 \| InternKon: 933 854 40 / 28
29	255 985 40	Plug	1	InternBDB: VSTI M14x1,5 ED / WN 34191340 \| InternKon: 933 854 40 / 37
30	932 713 40	Water hose l=0,19m	2	InternBDB: 307-75x190 \| InternKon: 933 854 40 / 30
31	269 742 40	Plug	1	InternBDB: 1/4" NPT / Licoln \| InternKon: 933 854 40 / 38
32	506 215 98	Pair of clamps	2	InternBDB: L-2-G-14 / DIN 3015 \| InternKon: 933 854 40 / 32
32	518 039 98	Pair of clamps (Cold weather design)	2	InternBDB: L-2-G-14 / DIN 3015 \| InternKon: 933 854 40 / 32
33	319 132 99	Screw	2	InternBDB: M6x25 / DIN 912 \| InternKon: 933 854 40 / 33
34	340 405 99	Washer	2	InternBDB: 6,4 / DIN 433 \| InternKon: 933 854 40 / 34
35	533 989 99	Weld on plate	1	InternBDB: L-AP-K-2 / DIN 3015 \| InternKon: 891 728 40 / 5
36	891 725 40	Clamp	1	InternKon: 933 857 40 / 5
37	307 780 99	Bolt	1	InternBDB: M10x35 / DIN 933 \| InternKon: 933 857 40 / 11
38	507 037 98	Nut	1	InternBDB: M 10 / DIN 985 \| InternKon: 933 857 40 / 14
39	340 465 99	Washer	1	InternBDB: B 10,5 / DIN 125 \| InternKon: 933 857 40 / 16
40	894 403 40	Plate	1	InternKon: 933 857 40 / 3
41	490 020 40	Clamp	3	InternBDB: Norma mit Konsole 2-tlg. D=133 \| InternKon: 933 857 40 / 9
42	307 754 99	Bolt	6	InternBDB: M8x25 / DIN 933 \| InternKon: 933 857 40 / 10
43	334 599 99	Nut	6	InternBDB: M 8 / DIN 985 \| InternKon: 933 857 40 / 13
44	937 903 40	Retainer	1	InternKon: 933 857 40 / 7
45	340 464 99	Washer	12	InternBDB: B 8,4 / DIN 125 \| InternKon: 933 857 40 / 20
