01 |
894 583 40
|
Temperature sensor assy. |
2 |
InternBDB: TL | InternKon: 921 567 40 / 4
|
|
|
|
02 |
894 576 40
|
Temperature sensor assy. |
1 |
InternBDB: TL | InternKon: 894 583 40 / 1
|
|
|
|
03 |
907 651 40
|
Temperature sensor |
1 |
InternBDB: 420 236 G1/2 PT100-4Leiter Bedia | InternKon: 894 576 40 / 1
|
|
|
|
04 |
056 070 40
|
Cable sleeve 1,0 - 1,5 |
4 |
|
|
|
|
05 |
795 496 73
|
Plug assy. |
1 |
InternBDB: 0819214020 KES 08192
|
|
|
|
06 |
940 169 40
|
Cable 4x1 |
-2 |
|
|
|
|
07 |
896 520 40
|
End pin |
1 |
InternBDB: 3,0x25 Pflitsch
|
|
|
|
08 |
907 705 40
|
Cable union |
1 |
InternBDB: Pflitsch YNPM 5x25 22051
|
|
|
|
09 |
907 692 40
|
Fitting DN 16/12 |
2 |
InternBDB: BVIR-M162
|
|
|
|
10 |
655 650 40
|
Cable protection hose DN 12 |
-2 |
InternBDB: VCST-12 B
|
|
|
|
11 |
795 495 73
|
Plug |
1 |
InternBDB: 0819214920 KES 08192 | InternKon: 894 583 40 / 2
|
|
|
|
12 |
055 140 40
|
Cable shoe |
4 |
InternBDB: 0,5-1,0 | InternKon: 894 583 40 / 3
|
|
|
|
13 |
907 653 40
|
Insulating tube |
-2 |
InternBDB: 91F3752 | InternKon: 894 583 40 / 4
|
|
|
|
14 |
056 292 40
|
Cable strap |
5 |
InternBDB: Ty 23 11 | InternKon: 894 576 40 / 4
|
|
|
|
15 |
256 514 40
|
Name plate |
5 |
InternKon: 894 576 40 / 3
|
|
|
|
16 |
795 497 73
|
Plug |
1 |
InternBDB: 0819224820 KES 08192 | InternKon: 894 576 40 / 2
|
|
|
|
18 |
006 339 98
|
Clamp |
14 |
InternBDB: RSGU 1100 18/15 | InternKon: 910 798 40 / 1
|
|
|
|
19 |
006 303 98
|
Clamp |
7 |
InternBDB: RSGU 1100 22/15 | InternKon: 910 799 40 / 1
|
|
|
|
20 |
510 210 98
|
Thread pin |
21 |
InternBDB: M6x20/32500 | InternKon: 910 799 40 / 2
|
|
|
|
21 |
507 025 98
|
Nut |
21 |
InternBDB: M6/985
|
|
|
|
30 |
943 263 40
|
Harness - pump d. gearoil - engine 1 |
1 |
InternKon: 943 265 40 / 1
|
|
|
|
31 |
943 264 40
|
Harness - pump d. gearoil - engine 2 |
1 |
InternKon: 943 265 40 / 2
|
|
|
|
32 |
0443451510
|
Clip NW 15 |
22 |
InternBDB: 77 KES 04434 | InternKon: 943 265 40 / 3
|
|
|
|
33 |
0443452712
|
Clip NW 27 |
8 |
InternBDB: 77 KES 04434 | InternKon: 943 265 40 / 4
|
|
|
|
34 |
896 669 40
|
Level probe |
2 |
InternBDB: 3/8" NPTF 425 031 MIT KABELENDEN | InternKon: 943 265 40 / 5
|
|
|
|
35 |
932 505 40
|
Adapter |
2 |
InternBDB: 3/4X3/8PTRM | InternKon: 943 265 40 / 6
|
|
|
|
36 |
795 461 73
|
Receptacle assy |
2 |
InternBDB: KES 08192 | InternKon: 943 265 40 / 7
|
|
|
|
37 |
307 773 99
|
Bolt |
8 |
InternBDB: M10X16 /DIN 00933 | InternKon: 943 265 40 / 8
|
|
|
|
38 |
340 465 99
|
Washer |
16 |
InternBDB: B 10,5 /DIN 00125 | InternKon: 943 265 40 / 9
|
|
|
|
39 |
507 037 98
|
Nut |
8 |
InternBDB: M10 /DIN 00985 | InternKon: 943 265 40 / 10
|
|
|
|
40 |
795 134 73
|
Plug assy. |
1 |
InternBDB: KES 08192 | InternKon: 943 264 40 / 1
|
|
|
|
41 |
907 703 40
|
Cable union |
1 |
InternBDB: 21650YNPM4X3 | InternKon: 943 264 40 / 3
|
|
|
|
42 |
515 213 40
|
Cable 1,0 |
-2 |
InternBDB: PUR-LITZE 1,0MM2 BLAU | InternKon: 943 264 40 / 9
|
|
|
|
43 |
940 462 40
|
Insulating tube |
-2 |
InternBDB: B 6 X0,6 PUR 70 SHORE | InternKon: 943 264 40 / 10
|
|
