01 |
767 997 73
|
Pressure sequence stage |
1 |
InternBDB: MHDBZ 04 K9-10/420 B09 /09 M01 867 765
|
|
|
|
02 |
|
Valve seat |
1 |
InternBDB: 867 767 /4,0-M28x1,5x43,5
|
|
|
|
03 |
|
Taper |
1 |
InternBDB: 144 258 /4,0-5,4x12,5 Z 5,4
|
|
|
|
04 |
|
Set screw |
1 |
InternBDB: 636 835 /M18x1,0x54,0
|
|
|
|
05 |
|
Nut |
1 |
InternBDB: 149 894 /M22x1,0
|
|
|
|
06 |
|
Nut |
1 |
InternBDB: 636 836 /M27x1,0
|
|
|
|
07 |
|
Set screw |
1 |
InternBDB: 636 837 /M24x1,0x32,0
|
|
|
|
08 |
|
Piston |
1 |
InternBDB: 149 891 /MHDBH 22 K9-10/D 18.0
|
|
|
|
09 |
|
Pin |
1 |
InternBDB: 149 892 /8,0x20,0 Z 5,4
|
|
|
|
10 |
515 019 98
|
O-ring |
1 |
InternBDB: 2528 /4,47x1,78-N-NBR 90
|
|
|
|
11 |
511 225 98
|
O-ring |
1 |
InternBDB: 4264 /15x2-N-NBR 90
|
|
|
|
12 |
515 020 98
|
O-ring |
1 |
InternBDB: 1885 /21,95x1,78-N-NBR 90
|
|
|
|
13 |
766 474 73
|
Washer |
1 |
InternBDB: 1276 /6,2 /12,0x0,5
|
|
|
|
14 |
340 627 99
|
Washer |
1 |
InternBDB: 3826 /6,0 /1440
|
|
|
|
15 |
|
Spring |
1 |
InternBDB: 2762 /8,6 /3,0x31,5 /7,0
|
|
|
|
16 |
504 261 98
|
O-ring |
1 |
InternBDB: 8972 /23,47x2,62-N-NBR 90
|
|
|
|
17 |
511 368 98
|
O-ring |
1 |
InternBDB: 4489 /12,37x2,62-N-NBR 90
|
|
|
|
18 |
766 475 73
|
Seal kit |
1 |
InternBDB: E-ST
|
|
