ee page Slew gearbox |
1 |
InternBDB: 944 872 40 | InternKon: 904 601 40 / 1
|
991-0870 |
|
|
? |
|
see page Slew gear motor |
1 |
InternBDB: 896 590 40 | InternKon: 938 523 40 / 13
|
991-0249 |
|
|
? |
|
see page Slew-brake valve |
1 |
InternBDB: 655 855 40 | InternKon: 938 523 40 / 14
|
991-0181a |
|
|
? |
514 693 40
|
Intermediate plate |
1 |
InternKon: 938 523 40 / 23
|
|
|
|
? |
356 209 40
|
O-ring |
4 |
InternBDB: 1 1/2 NBR 90 / 341 986 40
|
|
|
|
? |
319 286 99
|
Bolt |
4 |
InternBDB: M16x35 /912 | InternKon: 938 523 40 / 25
|
|
|
|
? |
501 784 98
|
Bolt |
4 |
InternBDB: M20x190 /912 | InternKon: 938 523 40 / 24
|
|
|
|
? |
307 454 99
|
Bolt |
8 |
InternBDB: M16x50 /933 | InternKon: 938 523 40 / 21
|
|
|
|
? |
316 211 99
|
Washer |
8 |
InternBDB: 17 / 6916 | InternKon: 938 523 40 / 22
|
|
|
|
? |
323 460 40
|
Bleeder valve |
3 |
InternBDB: Typ EV 1019 M22 x 1,5 | InternKon: 904 601 40 / 22
|
|
|
|
? |
517 612 98
|
Bolt |
34 |
InternBDB: M24x550 / DIN 912 / 12.9 | InternKon: 904 601 40 / 11
|
|
|
|
? |
516 920 98
|
Washer |
34 |
InternBDB: 25 / DIN 433 | InternKon: 904 601 40 / 12
|
|
|
|
? |
515 812 98
|
Coupling |
1 |
InternBDB: G1 / 4PC | InternKon: 938 523 40 / 26
|
|
|
|
? |
515 362 40
|
Oil drain coupling |
1 |
InternBDB: EV 1019 | InternKon: 904 601 40 / 21
|
|
|
|
? |
374 428 99
|
Union |
1 |
InternBDB: SDS-S 6x G1/4 A -TypeE /8434 | InternKon: 904 601 40 / 20
|
|
|
|
? |
507 037 98
|
Nut |
10 |
InternBDB: M 10 DIN00985 | InternKon: 904 601 40 / 6
|
|
|
|
? |
340 465 99
|
Washer |
10 |
InternBDB: 10,5 140HV DIN00125 DIN00125 | InternKon: 904 601 40 / 7
|
|
|
|
? |
507 488 98
|
Pin bolt |
10 |
InternBDB: PM 10 x 20 / 32500 | InternKon: 904 601 40 / 9
|
|
|
|
? |
506 129 98
|
Washer |
10 |
InternBDB: 13,5 / 440 | InternKon: 904 601 40 / 8
|
|
|
|
? |
945 988 40
|
Cover plate rear for Slew gear r.h. |
1 |
InternKon: 904 601 40 / 2
|
|
|
|
? |
938 534 40
|
Cover plate front for Slew gear r.h. |
1 |
InternKon: 904 601 40 / 3
|
|
|
|
? |
904 614 40
|
Cover plate rear for Slew gear l.h. |
1 |
InternKon: 904 601 40 / 4
|
|
|
|
? |
904 617 40
|
Cover plate front for Slew gear l.h. |
1 |
InternKon: 904 601 40 / 5
|
|
|
|
? |
308 639 99
|
Bolt |
4 |
InternBDB: M16x110 8.8 DIN00931 | InternKon: 904 601 40 / 10
|
|
|
|
? |
339 907 99
|
Seal ring |
6 |
|
|
|
|
? |
907 142 40
|
Plug |
34 |
InternBDB: Z36x25 GPN200 | InternKon: 904 601 40 / 19
|
|
|
|
? |
939 455 40
|
Pinion cover lh. |
1 |
InternKon: 904 601 40 / 13
|
|
|
|
? |
939 460 40
|
Pinion cover rh. |
1 |
InternKon: 904 601 40 / 14
|
|
|
|
? |
510 730 98
|
Resilient sleeve |
4 |
InternBDB: 17/30x55 WN34194840 | InternKon: 904 601 40 / 23
|
|
