OPERATOR'S CAB - GLAZING | PC4000-6 S/N 08195 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
?	793 739 73	Front window	1	InternBDB: Fa. Matek 119500036VSG grьn 12 mm Cleff 310 306,ohne Rahmenbohr \| InternKon: 509 0200 00 / 1
?	769 530 73	Side window r.h. slidable 1522/462x1491x8	1	InternBDB: Fa. Matek 119500034 VSG grьn 8 mm /05009 DEM Cleff \| InternKon: 509 0200 00 / 3
?	769 531 73	Side window l.h. slidable 1522/462x1491x8	1	InternBDB: Fa. Matek 119500032 /05008 DEM Cleff \| InternKon: 509 0200 00 / 2
?	302 020 40	Rear pane 803x458x5	1
?	082 280 40	Filler section	-2	InternBDB: GHE 404 0002
?	082 279 40	Jam profile	-2	InternBDB: GHE 401 0012
?	511 541 98	Screw	85	InternBDB: M5x16 /933 \| InternKon: 509 0200 00 / 4
?	507 036 98	Nut	85	InternBDB: M 5 /985 \| InternKon: 509 0200 00 / 5
?	340 462 99	Washer	85	InternBDB: 5,3 /125 \| InternKon: 509 0200 00 / 6
?	769 532 73	Filler section	-2	InternBDB: Fa. Reiff GRE 2198 0411 700 Matek-Nr. 111000444
?	769 533 73	Jam profile	-2	InternBDB: Fa. Reiff 0788 300 4/6 EPDM Matek-Nr. 111000387
?	794 070 73	Lock	2	InternBDB: Cleff 911 132
?	794 071 73	Sliding window with inner frame	1	InternBDB: 05009 DEM 062 VSG grьn 8 mm
?	794 072 73	Upper fixed pane	1	InternBDB: 05009 DEM 050 VSG grьn 8 mm
?	794 073 73	Lower fixed pane	1	InternBDB: 05009 DEM 060 VSG grьn 8 mm
?	794 074 73	Sliding window with inner frame	1	InternBDB: 05008 DEM 062 VSG grьn 8 mm
?	794 075 73	Upper fixed pane	1	InternBDB: 05008 DEM 050 VSG grьn 8 mm
?	794 076 73	Lower fixed pane	1	InternBDB: 05008 DEM 060 VSG grьn 8 mm
?	794 146 73	Locking wedge	2	InternBDB: Cleff 911 133
?	514 307 98	Screw	6	InternBDB: M3x5 /965
