STEPS | PC4000-6 S/N 08195 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options	Reference
01	947 783 40	Steps	1	InternKon: 945 941 40 / 1
02	901 764 40	Stop	1	InternKon: 945 941 40 / 3
03		Hydraulic cylinder	1	InternBDB: D80/40/420 896 534 40 \| InternKon: 945 941 40 / 4	991-0462
04	896 535 40	Silent block	4	InternKon: 945 941 40 / 5
05	945 944 40	Plate	2	InternBDB: 6x70x158 \| InternKon: 945 941 40 / 13
06	504 193 98	Nut	2	InternBDB: M 24 /985 \| InternKon: 945 941 40 / 11
07	334 600 99	Nut	2	InternBDB: M 12 /985 \| InternKon: 945 941 40 / 12
12	515 337 98	Pin	2	InternBDB: 7x65x55 /1434 \| InternKon: 945 941 40 / 7
14	500 995 98	Washer	2	InternKon: 945 941 40 / 9
15	342 125 99	Cotter pin	2	InternBDB: 8x71 /94 \| InternKon: 945 941 40 / 10
17	897 517 40	Bearing set assy. fig-nos. 18-22	2	InternKon: 945 941 40 / 2
18	515 335 98	Dowel screw	2	InternBDB: M24x80 /609 \| InternKon: 897 517 40 / 1
19	897 543 40	Distance sleeve	2	InternKon: 897 517 40 / 2
20	501 102 98	Roller bearing	2	InternBDB: 6305 /625 \| InternKon: 897 517 40 / 3
21	515 339 98	Shaft seal	4	InternBDB: 6305 AV /011 203 99 \| InternKon: 897 517 40 / 4
22	515 336 98	Washer	2	InternBDB: 25 /433 \| InternKon: 897 517 40 / 5
23	514 709 98	Hose assy. DN 10x10100	2	InternBDB: 050 DOL12 DOL12/90 \| InternKon: 902 080 40 / 7
25	374 407 99	Socket	2	InternBDB: S 15 E-M /3901 \| InternKon: 902 080 40 / 47
26	551 987 40	Union	2	InternBDB: 15 / 12 - PL / OMD \| InternKon: 902 080 40 / 55
27	516 157 98	Union	2	InternBDB: L12 ST-NBR DIN03942 \| InternKon: 902 080 40 / 117
