PC5500-6E S/N 15060

Komatsu parts book diagram for PC5500-6E S/N 15060: INSTALLATION TOOL FOR CYLINDERS

01 02 03 04 04 05 05 06 06 06 07 07 07 08 08 08 09 09 10 11 11

	#	Part Number	Partname	Quantity	Options	Reference
	01	934 611 40	Installation tool assy. Boom cylinder	1	InternBDB: Ш 518mm \| InternKon: 934 610 40 / 1
	02	923 828 40	Installation tool assy. Stick cylinder	1	InternBDB: Ш 425mm \| InternKon: 934 610 40 / 2
	03	909 374 40	Installation tool assy. Bucket cylinder	1	InternBDB: Ш 386mm \| InternKon: 934 610 40 / 3
	04	934 612 40	Half clamp	2	InternBDB: Ш 518mm \| InternKon: 934 611 40 / 1
	05	318 478 40	Plate	4	InternBDB: 100x15x205 \| InternKon: 934 611 40 / 2
	06	308 324 99	Bolt	16	InternBDB: M 24x80 / 931 \| InternKon: 934 611 40 / 3
	07	332 359 99	Nut	16	InternBDB: M 24 / 934 \| InternKon: 934 611 40 / 4
	08	340 471 99	Washer	16	InternBDB: 25 / 125 \| InternKon: 934 611 40 / 5
	09	923 822 40	Half clamp	2	InternBDB: Ш 425mm \| InternKon: 923 828 40 / 1
	10	652 962 40	Plate	2	InternBDB: 12x100x200 \| InternKon: 909 374 40 / 2
	11	909 371 40	Half clamp	2	InternBDB: Ш 386mm \| InternKon: 909 374 40 / 1

Komatsu PC5500-6E S/N 15060 parts catalog PDF

INSTALLATION TOOL FOR CYLINDERS (515-4990) in PC5500-6E S/N 15060. Diagram image and parts list.
