BOOM - CATWALK | PC5500-6E S/N 15060 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
01	944 280 40	Ladder	1	InternKon: 945 211 40 / 1
02	938 002 40	Stair rail section	1	InternKon: 945 211 40 / 2
03	937 658 40	Stair rail section	4	InternKon: 945 211 40 / 3
04	938 005 40	Stair rail section	1	InternKon: 945 211 40 / 4
05	938 010 40	Retainer	11	InternKon: 945 211 40 / 5
06	938 013 40	Retainer	1	InternKon: 945 211 40 / 6
07	938 012 40	Retainer	1	InternKon: 945 211 40 / 7
08	938 011 40	Retainer	1	InternKon: 945 211 40 / 8
09	895 529 40	Thread plate	4	InternKon: 945 211 40 / 9
10	307 802 99	Bolt	8	InternBDB: M12X 25 /DIN 00933 \| InternKon: 945 211 40 / 10
11	517 118 98	Lock washer	30	InternBDB: 12 /WN 65593840 \| InternKon: 945 211 40 / 11
12	346 523 40	Grating	1	InternBDB: 2X40X480X1410 \| InternKon: 945 211 40 / 12
13	898 995 40	Plate	2	InternKon: 945 211 40 / 13
14	317 319 40	Threaded block	4	InternBDB: M 8 \| InternKon: 945 211 40 / 14
15	317 318 40	Wing nut, plastic	4	InternKon: 945 211 40 / 15
16	502 354 98	Bolt	4	InternBDB: M8X 40 /DIN 00963 \| InternKon: 945 211 40 / 16
17	923 249 40	Angle	2	InternKon: 945 211 40 / 17
18	938 022 40	Pipe	1	InternBDB: 38X 5X790 \| InternKon: 945 211 40 / 18
19	896 570 40	Plug	16	InternBDB: GL32 GPN 320 \| InternKon: 945 211 40 / 19
20	936 985 40	Cover plate	11	InternKon: 945 211 40 / 20
21	307 775 99	Bolt	44	InternBDB: M10X 20 /DIN 00933 \| InternKon: 945 211 40 / 21
22	343 065 99	Lock washer	44	InternBDB: 10,5 /DIN 00463 \| InternKon: 945 211 40 / 22
23	534 009 99	Weld on plate	15	InternBDB: S-AP-A-4 /DIN 03015 \| InternKon: 945 211 40 / 23
24	504 445 98	Clamp set	15	InternBDB: S-4-R-65 /DIN 03015 \| InternKon: 945 211 40 / 24
25	308 612 99	Bolt	30	InternBDB: M12X 100 /DIN 00931 \| InternKon: 945 211 40 / 25
26	504 709 98	Clamp set	14	InternBDB: S-3-R-38 /DIN 03015 \| InternKon: 945 211 40 / 26
27	534 004 99	Cover plate	14	InternBDB: S-DP-A-3 /DIN 03015 \| InternKon: 945 211 40 / 27
28	308 581 99	Bolt	28	InternBDB: M10X 70 /DIN 00931 \| InternKon: 945 211 40 / 28
29	509 309 98	Locking plate	14	InternBDB: SI 5 /WN 01183999 \| InternKon: 945 211 40 / 29
30	509 310 98	Locking plate	4	InternBDB: SI 6 /WN 01183999 \| InternKon: 945 211 40 / 30
