01 |
352 432 40
|
Top roller, assy. |
1 |
InternBDB: DBM AT-Nr.668 899
|
|
|
|
02 |
307 587 99
|
Bolt |
8 |
InternBDB: M12x30 /933 10.9 | InternKon: 352 432 40 / 8
|
|
|
|
03 |
340 467 99
|
Washer |
8 |
InternBDB: B 13 /125 | InternKon: 352 432 40 / 9
|
|
|
|
04 |
313 337 40
|
Axle stirrup |
4 |
InternKon: 352 432 40 / 5
|
|
|
|
05 |
313 333 40
|
Roller bearing |
2 |
InternKon: 352 432 40 / 2
|
|
|
|
06 |
313 335 40
|
Stop washer |
2 |
InternKon: 352 432 40 / 4
|
|
|
|
07 |
324 067 40
|
Lifetime seal |
2 |
InternBDB: Goetze 76.90 H12 A3 | InternKon: 352 432 40 / 6
|
|
|
|
08 |
502 869 98
|
O-ring |
2 |
InternBDB: 71x5 /70 3770 | InternKon: 352 432 40 / 7
|
|
|
|
09 |
361 005 40
|
Top roller body with bush |
1 |
InternKon: 352 432 40 / 1
|
|
|
|
10 |
361 006 40
|
Top roller body |
1 |
InternKon: 361 005 40 / 1
|
|
|
|
11 |
313 336 40
|
Freeze-in bush |
2 |
InternBDB: 100/80x60 keine Nacharbeit erforderlich | InternKon: 361 005 40 / 2
|
|
|
|
12 |
339 918 99
|
Seal ring |
1 |
InternBDB: A26x32x2 / 7603 | InternKon: 352 432 40 / 11
|
|
|
|
13 |
349 989 99
|
Plug |
1 |
InternBDB: M26x1,5 /7604 | InternKon: 352 432 40 / 10
|
|
|
|
14 |
352 439 40
|
Axle |
1 |
InternBDB: Ш 80x460 | InternKon: 352 432 40 / 3
|
|
|
|
|$$15 |
694 484
|
Seal kit
fig-nos: 07,08,12 and 13 |
-2 |
InternBDB: E-ST
|
|
|
|
|$$16 |
|
Top roller is filled with oil |
-2 |
InternBDB: 7 l C-LP 220 002 018 99
|
|
