SAA6D170E-2A S/N 17389-UP

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	6162-15-1100	CYLINDER HEAD ASS'Y,VALVE LESS	6	SN: 17389-UP
?		HEAD	1	SN: 17389-UP
?	6162-13-1130	SLEEVE	1	SN: 17389-UP
?	6162-12-1152	O-RING (K1)	1	SN: 17389-UP
?	6162-15-1370	INSERT,INTAKE VALVE (STD)	2	SN: 17389-UP
?	6162-19-1370	INSERT¤ 0.25MM,INTAKE VALVE (OS)	2	SN: 17389-UP
?	6162-18-1370	INSERT¤ 0.50MM,INTAKE VALVE (OS)	2	SN: 17389-UP
?	6162-17-1370	INSERT¤ 0.75MM,INTAKE VALVE (OS)	2	SN: 17389-UP
?	6162-16-1370	INSERT¤ 1.00MM,INTAKE VALVE (OS)	2	SN: 17389-UP
?	6162-13-1322	INSERT,EXHAUST VALVE (STD)	2	SN: 17389-UP
?	6162-19-1322	INSERT¤ 0.25MM,EXHAUST VALVE (OS)	2	SN: 17389-UP
?	6162-18-1322	INSERT¤ 0.50MM,EXHAUST VALVE (OS)	2	SN: 17389-UP
?	6162-17-1322	INSERT¤ 0.75MM,EXHAUST VALVE (OS)	2	SN: 17389-UP
?	6162-16-1322	INSERT¤ 1.00MM,EXHAUST VALVE (OS)	2	SN: 17389-UP
?	6162-16-1341	GUIDE,VALVE	4	SN: 17389-UP
?	6162-13-1160	TUBE,PUSH ROD	2	SN: 17389-UP
?	07000-73028	O-RING	2	SN: 20321-UP
?	07000-63028	O-RING (K1)	2	SN: 17389-20320
?	07043-50108	PLUG	4	SN: 17389-UP
?	07043-50211	PLUG	1	SN: 17389-UP
?	6162-13-1150	PLUG,EXPANSION	17	SN: 17389-UP
?	6162-13-1140	GUIDE,CROSSHEAD	2	SN: 17389-UP
?	6162-13-1410	PIN,DOWEL	2	SN: 17389-UP
?	6162-43-4131	VALVE,INTAKE	12	SN: 17389-UP
?	6162-43-4230	VALVE,EXHAUST	12	SN: 17389-UP
?	6162-43-4440	SPRING,VALVE¤ INTAKE	12	SN: 20417-UP
?	6162-43-4440	SPRING,VALVE¤ OUTER	24	SN: 17389-20416
?	6162-43-4450	SPRING,VALVE¤ EXHAUST	12	SN: 20417-UP
?	6162-43-4420	SPRING,VALVE¤ INTAKE	12	SN: 20417-UP
?	6162-43-4420	SPRING,VALVE¤ INNER	24	SN: 17389-20416
?	6162-43-4460	SPRING,VALVE¤ EXHAUST	12	SN: 20417-UP
?	6162-42-4520	COTTER,VALVE	48	SN: 17389-UP
?	6162-43-4430	SEAT,SPRING¤ LOWER	24	SN: 17389-UP
?	6162-43-4511	SEAT,SPRING¤ UPPER	24	SN: 17389-UP
?	6162-43-5622	CROSSHEAD	12	SN: 18283-UP
?	6162-43-5621	CROSSHEAD	12	SN: 17389-18282
?	6162-43-5641	SCREW,ADJUST	12	SN: 20527-UP
?	6162-43-5640	SCREW,ADJUST	12	SN: 17389-20526
?	6162-43-5630	NUT,LOCK	12	SN: 17389-UP
?	6162-15-1610	BOLT	36	SN: 17389-UP
?	6162-13-1620	WASHER	36	SN: 17389-UP
?	6162-13-1812	GASKET (K1)	6	SN: 17389-UP
?	6162-13-1820	GROMMET,OIL	2	SN: 17389-UP
?	6162-13-1832	GROMMET,WATER	1	SN: 17389-UP
?	6162-13-1840	GROMMET,OIL	1	SN: 17389-UP
?	6162-13-1851	GROMMET,WATER	1	SN: 17389-UP
