01 |
698 245 73
|
Hydr. grease pump, H 55, H 65 (25 l) H 55, H 65 |
1 |
InternBDB: Modell-Nr. 84943
|
|
|
|
02 |
698 246 73
|
Hydr. grease pump, H 95, H 135 (60 l) H 95, H 135 |
1 |
InternBDB: 984960-E
|
|
|
|
03 |
698 247 73
|
Hydr. grease pump, H 185 - H 485 (200 l) H 185 - H 485 |
1 |
InternBDB: 84962
|
|
|
|
04 |
693 938
|
Suction tube to fig-no: 01 |
1 |
InternBDB: 61293 /18 - 7/8" Tauchtiefe
|
|
|
|
05 |
764 523 73
|
Suction tube to fig-no: 02 |
1 |
InternBDB: 961007-E Tauchtiefe 25-1/8"
|
|
|
|
06 |
693 825
|
Suction tube to fig-no: 03 |
1 |
InternBDB: 61285 /33 - 15/16" Tauchtiefe
|
|
|
|
07 |
693 939
|
Piston rod to fig-no: 01 |
1 |
InternBDB: 11799
|
|
|
|
08 |
764 524 73
|
Piston rod to fig-no: 02 |
1 |
InternBDB: 913003-E
|
|
|
|
09 |
693 827
|
Piston rod to fig-no: 03 |
1 |
InternBDB: 11761
|
|
|
|
10 |
693 814
|
Pin |
1 |
InternBDB: 11329
|
|
|
|
11 |
697 756 73
|
Piston |
1 |
InternBDB: 11340
|
|
|
|
12 |
693 816
|
Bushing |
1 |
InternBDB: 12333
|
|
|
|
13 |
693 817
|
Disc |
1 |
InternBDB: 48268
|
|
|
|
14 |
693 818
|
Seal ring |
1 |
InternBDB: 34180
|
|
|
|
15 |
693 819
|
Seal |
1 |
InternBDB: 31050
|
|
|
|
16 |
693 820
|
Sliding ring |
1 |
InternBDB: 14940
|
|
|
|
17 |
693 821
|
O-ring |
1 |
InternBDB: 34572
|
|
|
|
18 |
693 822
|
V-seal |
1 |
InternBDB: 38165
|
|
|
|
19 |
693 823
|
Elastic washer |
1 |
InternBDB: 48213
|
|
|
|
20 |
697 755 73
|
Seal |
1 |
InternBDB: 31054
|
|
|
|
21 |
693 829
|
Piston guide |
1 |
InternBDB: 11349
|
|
|
|
22 |
693 830
|
Seal |
1 |
InternBDB: 31048
|
|
|
|
23 |
693 831
|
Bushing |
1 |
InternBDB: 11345
|
|
|
|
24 |
693 832
|
Bolt |
1 |
InternBDB: 11346
|
|
|
|
25 |
693 833
|
Pin |
1 |
InternBDB: 11344
|
|
|
|
26 |
698 248 73
|
Ball retainer |
2 |
InternBDB: 57027
|
|
|
|
27 |
698 249 73
|
Ball |
2 |
InternBDB: 66010
|
|
|
|
28 |
693 835
|
Seal |
2 |
InternBDB: 31049
|
|
|
|
29 |
697 749 73
|
Cylinder assy. |
1 |
InternBDB: 90554
|
|
|
|
30 |
696 081 73
|
Seal ring |
1 |
InternBDB: 31047
|
|
|
|
31 |
698 250 73
|
Ball seat |
1 |
InternBDB: 11726
|
|
|
|
32 |
693 837
|
Valve stop |
1 |
InternBDB: 11722
|
|
|
|
33 |
693 838
|
Seal ring |
1 |
InternBDB: 35073
|
|
|
|
34 |
693 839
|
Distance plate |
1 |
InternBDB: 11702
|
|
|
|
35 |
697 275 73
|
Valve |
1 |
InternBDB: 11721
|
|
|
|
36 |
697 276 73
|
Valve seat |
1 |
InternBDB: 11725
|
|
|
|
37 |
693 836
|
Rod |
1 |
InternBDB: 11723
|
|
|
|
38 |
697 277 73
|
Suction piston |
1 |
InternBDB: 11724
|
|
|
|
39 |
697 750 73
|
Extension piece |
1 |
InternBDB: 61273
|
|
|
|
40 |
698 251 73
|
Suction tube |
1 |
InternBDB: 239719
|
|
|
|
41 |
698 252 73
|
Housing |
1 |
InternBDB: 241799
|
|
|
|
42 |
698 278 73
|
Cylinder |
1 |
InternBDB: 241814
|
|
|
|
43 |
698 253 73
|
Mounting plate |
1 |
InternBDB: 241803
|
|
|
|
44 |
698 254 73
|
Rod |
4 |
InternBDB: 241804
|
|
|
|
45 |
698 255 73
|
Nut |
1 |
InternBDB: 241805
|
|
|
|
46 |
764 525 73
|
Repair kit - pump |
1 |
InternBDB: E-ST 983009-E
|
|
|
|
47 |
698 257 73
|
Bolt |
4 |
InternBDB: 242048
|
|
|
|
48 |
698 258 73
|
Lock washer |
12 |
InternBDB: 66186
|
|
|
|
49 |
698 259 73
|
Lock washer |
2 |
InternBDB: 66220
|
|
|
|
50 |
698 260 73
|
Bolt |
8 |
InternBDB: 50771
|
|
|
|
51 |
695 729 73
|
Bolt |
2 |
InternBDB: 50058
|
|
|
|
52 |
698 261 73
|
Bolt |
2 |
InternBDB: 50178
|
|
|
|
53 |
698 262 73
|
Housing |
1 |
InternBDB: 40537
|
|
|
|
54 |
698 263 73
|
Union |
1 |
InternBDB: 15184
|
|
|
|
55 |
698 264 73
|
Lock washer |
2 |
InternBDB: 48083
|
|
|
|
56 |
698 265 73
|
Valve combination |
1 |
InternBDB: 84970
|
|
|
|
57 |
698 266 73
|
Hose |
1 |
InternBDB: 241806
|
|
|
|
58 |
698 267 73
|
Seal |
2 |
InternBDB: 241810
|
|
|
|
59 |
698 268 73
|
Hose |
1 |
InternBDB: 241963
|
|
|
|
60 |
698 269 73
|
Adapter |
2 |
InternBDB: 241961
|
|
|
|
61 |
698 270 73
|
3-Way-valve |
1 |
InternBDB: 242205
|
|
|
|
62 |
698 271 73
|
4-Way-valve |
1 |
InternBDB: 242208
|
|
|
|
63 |
698 272 73
|
Field coil |
2 |
InternBDB: 242206
|
|
|
|
64 |
698 273 73
|
Pressure reducing valve |
1 |
InternBDB: 242 207
|
|
|
|
65 |
698 274 73
|
Cable union |
2 |
InternBDB: 242 209
|
|
|
|
66 |
698 275 73
|
Pressure gauge |
1 |
InternBDB: 242 211
|
|
|
|
67 |
698 276 73
|
Flow control valve |
1 |
InternBDB: 242 631
|
|
|
|
68 |
698 277 73
|
Valve housing |
1 |
InternBDB: 242 204
|
|
|
|
69 |
697 141 73
|
Union |
1 |
InternBDB: GE 10-L 1/4 NPT 66846-E
|
|
|
|
70 |
698 418 73
|
Plug (for pressure lubrication) |
1 |
InternBDB: 67007
|
|
|
|
|$$71 |
764 161 73
|
Repair kits to suction tube
01-03 consist. of fig-nos:
27,30,31,33-38 |
1 |
InternBDB: Nr. 83 001
|
|
|
|
|$$72 |
006 695 98
|
O-ring to fig-nos. 61,62 |
2 |
InternBDB: 20x2,5 NB 90
|
|
