H65 26051

01 02 03 04 04 04 05 06 06 06 07 08 09 09 10 11 12 12 13 14 15 16 16 17 18 18 19 20 20 20 20 20 20 20 20 21 21 21 21 21 21 21 21 22 22 22 22 23 23 23 23 24 24 25 25 26 27 28 29

#	Part Number	Partname	Quantity	Options	Reference
01	324 828 40	Control block assy.	1	InternBDB: Rexroth MO-3136-00/ 3 MO-32 AT-Nr. 669 111 73
02	961 241	Vent screw	3	InternBDB: 117 640 \| InternKon: MO 3002-0-3-1 / 49
03	339 861 99	Seal ring	3	InternBDB: A6x10 /7603 \| InternKon: MO 3002-0-3-1 / 86
04	319 140 99	Screw	12	InternBDB: M8x20 /912 \| InternKon: MO 3002-0-3-1 / 72
05	753 720	Cover	3	InternBDB: 150 773 \| InternKon: MO 3002-0-3-1 / 17
06	501 049 98	O-ring	6	InternBDB: 63,17x2,62 \| InternKon: MO 3002-0-3-1 / 94
07	999 516	Snap ring	3	InternBDB: 150 768 \| InternKon: MO 3002-0-3-1 / 43
08	999 517	Ring	3	InternBDB: 150 767 \| InternKon: MO 3002-0-3-1 / 40
09	753 723	Spring plate	6	InternBDB: 150 766 \| InternKon: MO 3002-0-3-1 / 44
10	753 724	Spring	3	InternBDB: 001 461 \| InternKon: MO 3002-0-3-1 / 61
11	753 725	Spring	3	InternBDB: 001 570 \| InternKon: MO 3002-0-3-1 / 62
12	754 427	Cover	2	InternBDB: 168 358 \| InternKon: MO 3002-0-3-1 / 16
13	754 231	Spindle	2	InternBDB: 146 174 \| InternKon: MO 3002-0-3-1 / 50
14	754 162	Nut	2	InternBDB: 001 551 \| InternKon: MO 3002-0-3-1 / 96
15	994 822	Cover	1	InternBDB: 150 772 \| InternKon: MO 3002-0-3-1 / 12
16	756 254 73	Piston assy. For replacement state s/no. of block	2	InternBDB: 302 569 \| InternKon: MO 3002-0-3-1 / 36
17	754 067	Piston assy. For replacement state s/no. of block	1	InternBDB: 319 524 \| InternKon: MO 3002-0-3-1 / 37
18	753 727	Seal kit for piston axle	3	InternBDB: 309 628
19		Pressure relief valve	1	InternBDB: MHDB-40K2- 1x/420YM (MO-7004) 307 942 \| InternKon: MO 3002-0-3-1 / 60	090-0186
20	000 157 98	O-ring	16	InternBDB: 18x2,5
21	368 097 40	Support ring	16	InternBDB: 194 313
22	994 410	Plate	4	InternBDB: AG 7123 303 897 \| InternKon: MO 3002-0-3-1 / 139
23	319 429 99	Bolt	16	InternBDB: M10x20 /912 \| InternKon: MO 3002-0-3-1 / 78
24		Anticavitation valve	2	InternBDB: MHSV22ZB1- 1x/M(MO-7151) 307 121 \| InternKon: MO 3002-0-3-1 / 144	090-0226
25		Bleed-off valve	2	InternBDB: MHDBD22P2- 1x/420M (AG 7041) 303 354 \| InternKon: MO 3002-0-3-1 / 163	090-0198
26	319 264 99	Bolt	8	InternBDB: M10x90 /912 10.9 \| InternKon: MO 3002-0-3-1 / 81
27	999 525	Plug	1	InternBDB: 131 012 \| InternKon: MO 3002-0-3-1 / 47
28	500 582 98	O-ring	1	InternBDB: 38x3 \| InternKon: MO 3002-0-3-1 / 90
29	756 255 73	Plate assy. (with o-ring and bolt)	1	InternBDB: 319 320 Schraube: M12x25 /912 \| InternKon: MO 3002-0-3-1 / 187

Komatsu H65 26051 parts catalog PDF

CONTROL BLOCK (090-0443) in H65 26051. Diagram image and parts list.
