324 827 40
|
Hydr.-motor, assy. |
1 |
InternBDB: Hydromatik A2F M 125/ 61 W PAB 02 409 634 AT-Nr. 669 068 73
|
|
|
|
? |
|
Housing |
1 |
InternBDB: 409 518 | InternKon: 211.22.25.42 / 03
|
|
|
|
? |
319 156 99
|
Bolt |
2 |
InternBDB: M12x30 /912 | InternKon: 211.22.25.42 / 07
|
|
|
|
? |
343 856 99
|
Lock washer |
6 |
InternBDB: 12 /7980 | InternKon: 211.22.25.42 / 08
|
|
|
|
? |
319 439 99
|
Bolt |
4 |
InternBDB: M12x90 /912 | InternKon: 211.22.25.42 / 10
|
|
|
|
? |
754 862 73
|
Connection plate |
1 |
InternBDB: 409 552 | InternKon: 211.22.25.42 / 04
|
|
|
|
? |
972 199
|
O-ring |
1 |
InternBDB: 98,02x3,53 241-7507 | InternKon: 211.22.25.42 / 06
|
|
|
|
? |
344 791 99
|
Pin |
1 |
InternBDB: 6 M6x12 /7-ST | InternKon: 211.22.25.42 / 05
|
|
|
|
? |
754 863 73
|
Transmission, assy.
fig-nos: 10,17-30 |
1 |
InternBDB: 409 619 | InternKon: 211.22.25.42 / 01
|
|
|
|
? |
754 864 73
|
Transmission, assy.
fig-nos: 11-16 |
1 |
InternBDB: 418 927
|
|
|
|
? |
754 865 73
|
Control plate |
1 |
InternBDB: 409 545 | InternKon: 201.22.07.92 / 02
|
|
|
|
? |
754 866 73
|
Cylinder |
1 |
InternBDB: 409 484 | InternKon: 201.22.07.92 / 01
|
|
|
|
? |
754 867 73
|
Spring plate |
1 |
InternBDB: 416 980 | InternKon: 201.22.07.92 / 06
|
|
|
|
? |
753 679
|
Cup spring |
4 |
InternBDB: 400 105 | InternKon: 201.22.07.92 / 07
|
|
|
|
? |
753 680
|
Trunnion |
1 |
InternBDB: 409 486 | InternKon: 201.22.07.92 / 03
|
|
|
|
? |
754 686 73
|
Piston with piston ring |
7 |
InternBDB: 417 665 + 2x 156 196 | InternKon: 201.22.07.92 / 04
|
|
|
|
? |
753 682
|
Screw, burnished |
7 |
InternBDB: 153 648 M6x20-BR AF | InternKon: 201.22.07.10 / 20
|
|
|
|
? |
754 869 73
|
Withdrawal plate |
1 |
InternBDB: 417 737 | InternKon: 201.22.07.10 / 07
|
|
|
|
? |
753 686
|
Disk |
1 |
InternBDB: 409 612 | InternKon: 201.22.07.10 / 05
|
|
|
|
? |
754 870 73
|
Drive shaft with bearing set
with fig-nos: 21-23,27 |
1 |
InternBDB: 419 832 | InternKon: 201.22.07.10 / 02
|
|
|
|
? |
|
Roller bearing
These parts are not sold
separately |
1 |
InternBDB: 154 382 | InternKon: 201.22.07.10 / 10
|
|
|
|
? |
|
Race
These parts are not sold
separately |
1 |
InternBDB: 409 524 | InternKon: 201.22.07.10 / 03
|
|
|
|
? |
|
Roller bearing
These parts are not sold
separately |
1 |
InternBDB: 33111 /720 | InternKon: 201.22.07.10 / 11
|
|
|
|
? |
753 688
|
Shim ring 100x125x0,1 |
2 |
InternBDB: 154 359 | InternKon: 201.22.07.10 / 17
|
|
|
|
? |
753 689
|
Shim ring 100x125x0,3 |
1 |
InternBDB: 154 360 | InternKon: 201.22.07.10 / 18
|
|
|
|
? |
971 059
|
O-ring |
1 |
InternBDB: 117,07x3,53 247-7507 | InternKon: 201.22.07.10 / 15
|
|
|
|
? |
|
Groove nut
These parts are not sold
separately |
1 |
InternBDB: 156 020 | InternKon: 201.22.07.10 / 09
|
|
|
|
? |
180 863 40
|
Shaft seal
No field repair item |
1 |
InternBDB: 50x72x7/7,5 Drallfrei 827 SK | InternKon: 201.22.07.10 / 14
|
|
|
|
? |
754 871 73
|
Cover
No field repair item |
1 |
InternBDB: 409 482 | InternKon: 201.22.07.10 / 04
|
|
|
|
? |
342 675 99
|
Circlip |
1 |
InternBDB: 125x4 /472 | InternKon: 201.22.07.10 / 12
|
|
|
|
? |
753 690
|
Cover, assy.
with fig-no: 28 |
-2 |
InternBDB: 409 482 + 084 516
|
|
|
|
? |
754 457
|
Seal kit, assy.
fig-nos: 07,26,28 |
-2 |
InternBDB: E-ST
|
|
|
|
? |
973 125
|
Fluid sealing 50 ml
to fig-no: 17 |
-2 |
InternBDB: Loctite 241
|
|
|
|
? |
989 946
|
Fluid sealing 50 ml
(pipe thread) |
-2 |
InternBDB: Loctite 572
|
|
