00 |
324 831 40
|
Hydr. motor, assy. |
1 |
InternBDB: Hydromatik A2F E 125/61 W-PAL 10 418 426 AT-Nr. 669 064 73
|
|
|
|
02 |
|
Housing |
1 |
InternBDB: 419357 | InternKon: 211.22.01.90 / 3
|
|
|
|
03 |
319 156 99
|
Screw |
6 |
InternBDB: M12x30/912 | InternKon: 211.22.01.90 / 7
|
|
|
|
04 |
343 856 99
|
Lock washer |
6 |
InternBDB: 12/7980 | InternKon: 211.22.01.90 / 8
|
|
|
|
05 |
756 105 73
|
Connection plate |
1 |
InternBDB: 419211 | InternKon: 211.22.01.90 / 4
|
|
|
|
06 |
344 791 99
|
Pin |
1 |
InternBDB: 6 M6x12/7 | InternKon: 211.22.01.90 / 5
|
|
|
|
07 |
972 199
|
O-ring |
1 |
InternBDB: 086949 | InternKon: 211.22.01.90 / 6
|
|
|
|
08 |
754 863 73
|
Transmission, assy.
fig-nos: 09,18-25 |
1 |
InternBDB: 409619 | InternKon: 211.22.01.90 / 1
|
|
|
|
09 |
754 864 73
|
Transmission, assy.
fig-nos: 10-17 |
1 |
InternBDB: 418927
|
|
|
|
10 |
754 865 73
|
Control plate |
1 |
InternBDB: 409545 | InternKon: 418927 / 2
|
|
|
|
11 |
754 866 73
|
Cylinder |
1 |
InternBDB: 409484 | InternKon: 418927 / 1
|
|
|
|
12 |
343 266 99
|
Screw |
7 |
InternBDB: M6x20/7985 | InternKon: 418927 / 20
|
|
|
|
13 |
754 869 73
|
Withdrawel plate |
1 |
InternBDB: 417737 | InternKon: 418927 / 7
|
|
|
|
14 |
754 867 73
|
Spring plate |
1 |
InternBDB: 416980 | InternKon: 418927 / 6
|
|
|
|
15 |
753 679
|
Cup spring |
4 |
InternBDB: 400105 | InternKon: 418927 / 7
|
|
|
|
16 |
753 680
|
Trunnion |
1 |
InternBDB: 409486 | InternKon: 418927 / 3
|
|
|
|
17 |
754 868 73
|
Piston |
7 |
InternBDB: 417665+ 156196 | InternKon: 418927 / 4
|
|
|
|
18 |
753 686
|
Washer |
1 |
InternBDB: 409612 | InternKon: 409619 / 5
|
|
|
|
19 |
754 870 73
|
Drive shaft with bearing set |
1 |
InternBDB: 270852
|
|
|
|
20 |
753 688
|
Shim washer 100x125x0,1 |
2 |
InternBDB: 154359 | InternKon: 409619 / 17
|
|
|
|
21 |
753 689
|
Shim washer 100x125x0,3 |
1 |
InternBDB: 154360 | InternKon: 409619 / 18
|
|
|
|
22 |
971 059
|
O-ring |
1 |
InternBDB: 117,07x3,53 247-7507 | InternKon: 409619 / 15
|
|
|
|
23 |
753 690
|
Cover assy.
with fig-no: 24 |
1 |
InternBDB: 409482+ 084516 | InternKon: 409619 / 4
|
|
|
|
24 |
992 667
|
Shaft seal |
1 |
InternBDB: 084516 50x72x7 | InternKon: 409619 / 14
|
|
|
|
25 |
342 675 99
|
Circlip |
1 |
InternBDB: 125x4/472 | InternKon: 409619 / 12
|
|
|
|
|$$26 |
756 106 73
|
Repair kit
fig-nos: 07,22,24 |
-2 |
InternBDB: E-St
|
|
|
|
|$$27 |
973 125
|
Adhesive set to fig-no: 24 50 ml |
-2 |
InternBDB: Loctite 241
|
|
