01 |
414 163 40
|
Support roller, assy. |
1 |
InternBDB: Italtractor
|
|
|
|
02 |
695 637 73
|
Snap ring |
1 |
InternBDB: 0108-30C-10 | InternKon: 0108-31F-00 / 9
|
|
|
|
03 |
695 638 73
|
O-ring |
1 |
InternBDB: 0108-30C-09 Ш 8x32/7 | InternKon: 0108-31F-00 / 8
|
|
|
|
04 |
344 877 99
|
Pin |
2 |
InternBDB: 0107-30A-05/1 | InternKon: 0108-31F-00 / 7
|
|
|
|
05 |
695 639 73
|
Retainer, assy. |
1 |
InternBDB: 0108-30C-08 | InternKon: 0108-31F-00 / 6
|
|
|
|
06 |
695 660 73
|
Floating seal, assy. |
1 |
InternBDB: 0108-118-02 0108-118-01 E-ST | InternKon: 0108-31F-00 / 5
|
|
|
|
07 |
695 661 73
|
Axle |
1 |
InternBDB: 0108-30F-02 | InternKon: 0108-31F-00 / 3
|
|
|
|
08 |
695 662 73
|
Taper roller bearing |
2 |
InternBDB: 0220-3211-00 | InternKon: 0108-31F-00 / 2
|
|
|
|
10 |
695 663 73
|
Support roller body |
1 |
InternBDB: 0108-30-01 | InternKon: 0108-31F-00 / 1
|
|
|
|
12 |
695 664 73
|
Plate |
1 |
InternBDB: 0108-30F-14 | InternKon: 0108-31F-00 / 10
|
|
|
|
13 |
695 665 73
|
Lock |
1 |
InternBDB: 0105-30A-15 | InternKon: 0108-31F-00 / 11
|
|
|
|
14 |
695 666 73
|
O-ring |
1 |
InternBDB: 0106-30A-12 | InternKon: 0108-31F-00 / 13
|
|
|
|
15 |
695 667 73
|
Screw |
2 |
InternBDB: 0108-30-06 3/8x24 | InternKon: 0108-31F-00 / 12
|
|
|
|
16 |
695 668 73
|
Cover |
1 |
InternBDB: 0106-30A-11 | InternKon: 0108-31F-00 / 14
|
|
|
|
17 |
695 669 73
|
Lock washer |
3 |
InternBDB: 0107-12A-05 | InternKon: 0108-31F-00 / 15
|
|
|
|
18 |
695 670 73
|
Screw |
3 |
InternBDB: 0104-30-09 | InternKon: 0108-31F-00 / 16
|
|
|
|
19 |
695 671 73
|
O-ring |
1 |
InternBDB: 0107-12F-04 | InternKon: 0108-31F-00 / 18
|
|
|
|
20 |
695 672 73
|
Screw plug |
1 |
InternBDB: 0107-12F-03 | InternKon: 0108-31F-00 / 17
|
|
