01 |
440 058 40
|
Hose assy. NW 25 |
4 |
InternBDB: Typ GH506 SFL-6-90-1"/ SFL-6-1 1/4" | InternKon: 457 418 40 / 13
|
|
|
|
02 |
500 032 98
|
Flange |
8 |
InternBDB: FE-3800-16/6 | InternKon: 457 418 40 / 5
|
|
|
|
03 |
255 007 40
|
Hose assy. NW 12x3200 lg.
Bulk ware, state length
required |
2 |
InternBDB: Aeroquip 2651-10
|
|
|
|
04 |
697 231 73
|
Pipe assy. Ш 38 |
1 |
InternBDB: 428 338 40 | InternKon: 457 418 40 / 1
|
|
|
|
05 |
697 232 73
|
Pipe assy. Ш 38 |
1 |
InternBDB: 428 339 40 | InternKon: 457 418 40 / 2
|
|
|
|
06 |
697 233 73
|
Pipe assy. Ш 38 |
1 |
InternBDB: 428 341 40 | InternKon: 457 418 40 / 3
|
|
|
|
07 |
697 234 73
|
Pipe assy. Ш 38 |
1 |
InternBDB: 428 342 40 | InternKon: 457 418 40 / 4
|
|
|
|
08 |
006 638 98
|
Half flange |
16 |
InternBDB: 32/420 E-ST
|
|
|
|
09 |
006 725 98
|
O-ring |
4 |
InternBDB: 37,69x3,53 NB 90
|
|
|
|
10 |
319 209 99
|
Bolt |
32 |
InternBDB: M14x45/912
|
|
|
|
11 |
343 866 99
|
Lock washer |
16 |
InternBDB: 14/7980
|
|
|
|
12 |
180 113 40
|
Plug |
1 |
InternBDB: VSTI G1/4 ED
|
|
|
|
13 |
370 312 99
|
Union |
2 |
InternBDB: DL10/2353
|
|
|
|
14 |
185 278 40
|
Pipe assy. Ш 10 |
1 |
|
|
|
|
15 |
372 427 99
|
Union |
1 |
InternBDB: CL18/2353
|
|
|
|
16 |
421 289 40
|
Pipe assy. Ш 18 |
1 |
InternBDB: 18x1,5/2391
|
|
|
|
17 |
372 904 99
|
Union |
2 |
InternBDB: KOR18/15-L
|
|
|
|
18 |
500 451 98
|
Union |
1 |
InternBDB: EEL18/2353
|
|
|
|
19 |
385 245 40
|
Nipple |
2 |
InternBDB: Aeroquip 11-002-13-10
|
|
|
|
20 |
368 268 40
|
Nipple |
2 |
InternBDB: 11-030-13-10
|
|
|
|
21 |
255 008 40
|
Socket |
4 |
InternBDB: G 1210-10
|
|
|
|
22 |
372 426 99
|
Union |
2 |
InternBDB: CL 15 /2353
|
|
|
|
23 |
534 022 99
|
Clamp |
16 |
InternBDB: CS 5/38 | InternKon: 457 418 40 / 14
|
|
|
|
24 |
501 897 98
|
Collar ring |
4 |
InternBDB: K-3850-16 | InternKon: 457 418 40 / 7
|
|
|
|
25 |
534 004 99
|
Plate |
8 |
InternBDB: DS 5 | InternKon: 457 418 40 / 17
|
|
|
|
26 |
412 884 40
|
Threaded rod |
4 |
InternBDB: M12x245/975 5-6
|
|
|
|
27 |
333 174 99
|
Nut |
32 |
InternBDB: BM12/439
|
|
|
|
29 |
500 273 98
|
Collar ring |
4 |
InternBDB: KO-3850-16 | InternKon: 457 418 40 / 8
|
|
|
|
30 |
320 152 99
|
Bolt |
16 |
InternBDB: M12x75 /912 | InternKon: 457 418 40 / 12
|
|
|
|
31 |
332 334 99
|
Nut |
16 |
InternBDB: M 12 /934 | InternKon: 457 418 40 / 10
|
|
|
|
32 |
324 524 40
|
Quadring |
8 |
|
|
