H65 26051

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	256 425 40	4/2-Directional spool valve	1	InternBDB: Rexroth 4WE6 C50 AG 24 NZ 4 \| InternKon: 436 915 40 / 50
?	180 325 40	Base plate	1	InternBDB: G 342/1 \| InternKon: 436 915 40 / 51
?	694 485	Cube plug	1	InternBDB: 008 908
?	960 910	Magnet with emergency hand actuation	1	InternBDB: GU 35-4-A-355
?	500 287 98	O-ring	4	InternBDB: 007 111 9,25x1,78
?	971 231	O-ring	1	InternBDB: 009 091 15,6x1,78
?	502 461 98	Screw	4	InternBDB: 008 132 M4x65 /912
?	319 174 99	Screw	4	InternBDB: M5x50 /912 \| InternKon: 436 915 40 / 96
?	319 132 99	Screw	2	InternBDB: M6x25 /912
?	307 750 99	Bolt	2	InternBDB: M8x15 /933 \| InternKon: 436 915 40 / 98
?	332 110 99	Nut	2	InternBDB: M 6 /934 \| InternKon: 436 915 40 / 76
?	332 111 99	Nut	2	InternBDB: M 8 /934 \| InternKon: 436 915 40 / 75
?	255 694 40	Plug	3	InternBDB: vsti G 3/8 ed \| InternKon: 436 915 40 / 32
?	307 775 99	Bolt	2	InternBDB: M10x20 /933 \| InternKon: 436 915 40 / 63
?	317 453 40	Accumulator	1	InternBDB: Hydac SB0 100-0,7A 2.1 /113-0, P0=10 bar \| InternKon: 436 915 40 / 57
?	421 532 40	Distributor	1	InternKon: 436 915 40 / 18
?	372 413 99	Union	1	InternBDB: DS 12 /2353 \| InternKon: 436 915 40 / 64
?	505 358 98	Socket	1	InternBDB: EVGE 12-SR-ED \| InternKon: 436 915 40 / 73
?	370 312 99	Union	8	InternBDB: DL10/2353
?	159 966 40	Clamping ring	-2
?	007 577 40	Sleeve	-2
?	501 019 98	Plastic pipe Ш 10 Bulk ware, state length required	-2	InternBDB: 10x1/73378
?	421 550 40	Angle	1	InternKon: 436 915 40 / 12
?	374 416 99	Socket	20	InternBDB: L 10 G 1/4 / 3901 \| InternKon: 436 915 40 / 31
?	269 292 40	Hose fittings	14	InternBDB: Aeroquip 07.002-8-6 \| InternKon: 436 915 40 / 34
?	256 584 40	Hose NW 8 Bulk ware, state length required	8	InternBDB: Aeroquip 2651-6 \| InternKon: 436 915 40 / 36
?	372 462 99	Union	1	InternBDB: DS 20 /2353 \| InternKon: 436 915 40 / 26
?		Hose fittings	2	InternBDB: 38.721-20-10
?	269 432 40	Hose NW 16 Bulk ware, state length required	-2	InternBDB: FC 310-10
?	371 402 99	Non-return valve	1	InternBDB: RHZ 10-LR-ED \| InternKon: 436 915 40 / 28
?	371 952 99	Union	2	InternBDB: FFL10/2353

Komatsu H65 26051 parts catalog PDF

HYDR. CONTROL (065-1851) in H65 26051. Diagram image and parts list.
