01 |
256 425 40
|
4/2-Directional spool valve |
1 |
InternBDB: Rexroth 4WE6 C50 AG 24 NZ 4 | InternKon: 436 915 40 / 50
|
|
|
|
02 |
180 325 40
|
Base plate |
1 |
InternBDB: G 342/1 | InternKon: 436 915 40 / 51
|
|
|
|
03 |
694 485
|
Cube plug |
1 |
InternBDB: 008 908
|
|
|
|
04 |
960 910
|
Magnet with emergency hand
actuation |
1 |
InternBDB: GU 35-4-A-355
|
|
|
|
05 |
500 287 98
|
O-ring |
4 |
InternBDB: 007 111 9,25x1,78
|
|
|
|
06 |
971 231
|
O-ring |
1 |
InternBDB: 009 091 15,6x1,78
|
|
|
|
07 |
502 461 98
|
Screw |
4 |
InternBDB: 008 132 M4x65 /912
|
|
|
|
08 |
319 174 99
|
Screw |
4 |
InternBDB: M5x50 /912 | InternKon: 436 915 40 / 96
|
|
|
|
09 |
319 132 99
|
Screw |
2 |
InternBDB: M6x25 /912
|
|
|
|
10 |
307 750 99
|
Bolt |
2 |
InternBDB: M8x15 /933 | InternKon: 436 915 40 / 98
|
|
|
|
11 |
332 110 99
|
Nut |
2 |
InternBDB: M 6 /934 | InternKon: 436 915 40 / 76
|
|
|
|
12 |
332 111 99
|
Nut |
2 |
InternBDB: M 8 /934 | InternKon: 436 915 40 / 75
|
|
|
|
13 |
255 694 40
|
Plug |
3 |
InternBDB: vsti G 3/8 ed | InternKon: 436 915 40 / 32
|
|
|
|
14 |
307 775 99
|
Bolt |
2 |
InternBDB: M10x20 /933 | InternKon: 436 915 40 / 63
|
|
|
|
15 |
317 453 40
|
Accumulator |
1 |
InternBDB: Hydac SB0 100-0,7A 2.1 /113-0, P0=10 bar | InternKon: 436 915 40 / 57
|
|
|
|
16 |
421 532 40
|
Distributor |
1 |
InternKon: 436 915 40 / 18
|
|
|
|
17 |
372 413 99
|
Union |
1 |
InternBDB: DS 12 /2353 | InternKon: 436 915 40 / 64
|
|
|
|
18 |
505 358 98
|
Socket |
1 |
InternBDB: EVGE 12-SR-ED | InternKon: 436 915 40 / 73
|
|
|
|
19 |
370 312 99
|
Union |
8 |
InternBDB: DL10/2353
|
|
|
|
20 |
159 966 40
|
Clamping ring |
-2 |
|
|
|
|
21 |
007 577 40
|
Sleeve |
-2 |
|
|
|
|
22 |
501 019 98
|
Plastic pipe Ш 10
Bulk ware, state length
required |
-2 |
InternBDB: 10x1/73378
|
|
|
|
23 |
421 550 40
|
Angle |
1 |
InternKon: 436 915 40 / 12
|
|
|
|
24 |
374 416 99
|
Socket |
20 |
InternBDB: L 10 G 1/4 / 3901 | InternKon: 436 915 40 / 31
|
|
|
|
25 |
269 292 40
|
Hose fittings |
14 |
InternBDB: Aeroquip 07.002-8-6 | InternKon: 436 915 40 / 34
|
|
|
|
26 |
256 584 40
|
Hose NW 8
Bulk ware, state length
required |
8 |
InternBDB: Aeroquip 2651-6 | InternKon: 436 915 40 / 36
|
|
|
|
27 |
372 462 99
|
Union |
1 |
InternBDB: DS 20 /2353 | InternKon: 436 915 40 / 26
|
|
|
|
28 |
|
Hose fittings |
2 |
InternBDB: 38.721-20-10
|
|
|
|
29 |
269 432 40
|
Hose NW 16
Bulk ware, state length
required |
-2 |
InternBDB: FC 310-10
|
|
|
|
30 |
371 402 99
|
Non-return valve |
1 |
InternBDB: RHZ 10-LR-ED | InternKon: 436 915 40 / 28
|
|
|
|
31 |
371 952 99
|
Union |
2 |
InternBDB: FFL10/2353
|
|
