00 |
641 944 40
|
Nitrogen-cylinder, l.h. and r.h.
fig-nos. 01-21 |
1 |
|
|
|
|
00 |
641 934 40
|
Nitrogen-cylinder, l.h. and r.h.
fig-nos. 01-21
(cold weather design) |
1 |
|
|
|
|
01 |
641 952 40
|
Nitrogen-cylinder l.h. |
1 |
InternBDB: TL 641 966 40 | InternKon: 641 944 40 / 1
|
|
|
|
01 |
641 953 40
|
Nitrogen-cylinder r.h. |
1 |
InternBDB: TL 641 966 40 | InternKon: 641 944 40 / 2
|
|
|
|
01 |
641 962 40
|
Nitrogen-cylinder l.h.
(cold weather design) |
1 |
InternBDB: AT-Nr. 710 364 73 | InternKon: 641 934 40 / 1
|
|
|
|
01 |
641 963 40
|
Nitrogen-cylinder r.h.
(cold weather design) |
1 |
InternBDB: AT-Nr. 710 365 73 | InternKon: 641 934 40 / 2
|
|
|
|
02 |
641 938 40
|
Cylinder |
1 |
InternKon: 641 962 40 / 1
|
|
|
|
03 |
304 276 40
|
Piston |
1 |
InternKon: 641 962 40 / 3
|
|
|
|
04 |
200 265 40
|
Piston ring |
1 |
InternBDB: Prдdifa F3 25x2,5 PTFE- | InternKon: 641 962 40 / 9
|
|
|
|
05 |
641 936 40
|
Flange |
1 |
InternKon: 641 962 40 / 4
|
|
|
|
06 |
202 956 40
|
Stripper |
1 |
InternBDB: Prдdifa 180x200x18 A5N 90 | InternKon: 641 962 40 / 12
|
|
|
|
07 |
319 339 99
|
Bolt |
13 |
InternBDB: M24x80 /912- 10.9 | InternKon: 641 962 40 / 17
|
|
|
|
07 |
501 455 98
|
Bolt
(cold weather design) |
13 |
InternBDB: M24x80 /912- 10.9 | InternKon: 641 962 40 / 17
|
|
|
|
08 |
255 554 40
|
V-seal |
1 |
InternBDB: Merkel | InternKon: 641 962 40 / 11
|
|
|
|
08 |
490 263 40
|
V-seal
(cold weather design) |
1 |
InternBDB: Merkel 200x220x14 | InternKon: 641 962 40 / 11
|
|
|
|
09 |
200 264 40
|
Piston ring |
2 |
InternBDB: Prдdifa F3 25x2,5 PTFE | InternKon: 641 962 40 / 8
|
|
|
|
10 |
255 555 40
|
V-seal |
1 |
InternBDB: Merkel | InternKon: 641 962 40 / 10
|
|
|
|
10 |
490 262 40
|
V-seal
(cold weather design) |
1 |
InternBDB: Merkel 195x220x19 | InternKon: 641 962 40 / 10
|
|
|
|
11 |
200 261 40
|
Plug |
1 |
InternKon: 641 962 40 / 6
|
|
|
|
12 |
242 765 40
|
Plug |
1 |
InternKon: 641 962 40 / 7
|
|
|
|
13 |
256 422 40
|
Seal element |
1 |
InternBDB: Bu. u. Lu. S-55024-0080-46 | InternKon: 641 962 40 / 13
|
|
|
|
14 |
256 423 40
|
O-ring |
1 |
InternBDB: Bu. u. Lu. RDR 006-8307 | InternKon: 641 962 40 / 14
|
|
|
|
14 |
461 058 40
|
O-ring
(cold weather design) |
1 |
InternBDB: Bu. u. Lu. RDR 006-8307 | InternKon: 641 962 40 / 14
|
|
|
|
15 |
621 631 40
|
Tappet rod |
1 |
InternKon: 641 962 40 / 5
|
|
|
|
16 |
340 831 99
|
Spring |
1 |
InternKon: 641 962 40 / 15
|
|
|
|
17 |
691 413
|
Valve, assy.
fig-nos: 12,13,14,15,16 |
1 |
|
|
|
|
17 |
697 892 73
|
Valve, assy.
fig-nos: 12,13,14,15,16
(cold weather design) |
1 |
|
|
|
|
18 |
641 929 40
|
Protecting hood |
1 |
InternKon: 641 962 40 / 2
|
|
|
|
19 |
319 336 99
|
Bolt |
2 |
InternBDB: M24x55 /912 10.9 | InternKon: 641 962 40 / 18
|
|
|
|
19 |
511 847 98
|
Bolt
(cold weather design) |
2 |
InternBDB: M24x55 /912 10.9 | InternKon: 641 962 40 / 18
|
|
|
|
20 |
319 140 99
|
Bolt |
2 |
InternBDB: M8x20 /912 | InternKon: 641 962 40 / 19
|
|
|
|
21 |
634 695 40
|
Air filter |
1 |
InternBDB: Bosch 1427 432 000 M12x1,5 | InternKon: 641 962 40 / 16
|
|
|
|
|$$33 |
691 412
|
Seal kit
fig-nos: 04,06,08,09,10 |
1 |
|
|
|
|
|$$34 |
697 893 73
|
Seal kit
fig-nos: 04,06,08,09,10
(cold weather design) |
1 |
|
|
