650 470 40
|
Hydr. cylinder
consist. of fig-nos: 02-28 |
1 |
InternBDB: DBM 250x160x2940 Hub 1700
|
|
|
|
? |
764 761 73
|
Cylinder barrel
consist. of fig-nos: 03-06 |
1 |
InternBDB: E-St
|
|
|
|
? |
|
Cylinder
These parts are not sold
separately |
1 |
InternBDB: 425 445 40 | InternKon: 650 470 40 / 1
|
|
|
|
? |
627 567 40
|
Freeze-in bush |
2 |
InternBDB: n. Zchng. 630 333 40 | InternKon: 650 470 40 / 6
|
|
|
|
? |
575 792 40
|
Seal ring |
4 |
InternBDB: 150/140x4 n. Zchng. 575 861 40 | InternKon: 650 470 40 / 13
|
|
|
|
? |
004 860 98
|
Nipple |
3 |
InternBDB: AR1/4" 011 207 99 | InternKon: 650 470 40 / 21
|
|
|
|
? |
501 025 98
|
Thread pin |
1 |
InternBDB: M12x35/915 | InternKon: 650 470 40 / 20
|
|
|
|
? |
659 018 40
|
Groove nut |
1 |
InternKon: 650 470 40 / 5
|
|
|
|
? |
659 019 40
|
Piston |
1 |
InternKon: 650 470 40 / 4
|
|
|
|
? |
324 952 40
|
Piston guide 761 lg. |
2 |
InternBDB: Bu.u.Lu. S-50740-47 | InternKon: 650 470 40 / 10
|
|
|
|
? |
255 760 40
|
Piston guide |
4 |
InternBDB: Bu. u. Lu. BI-50706-2500-A-900 | InternKon: 650 470 40 / 9
|
|
|
|
? |
202 702 40
|
Seal |
1 |
InternBDB: Bu. u. Lu. S-55044-2500-46N | InternKon: 650 470 40 / 7
|
|
|
|
? |
202 703 40
|
O-ring |
1 |
InternBDB: Bu. u. Lu. 447-8307 | InternKon: 650 470 40 / 8
|
|
|
|
? |
256 601 40
|
Spiral-Backring |
2 |
InternBDB: Prдdifa 160x5/1,5 | InternKon: 650 470 40 / 17
|
|
|
|
? |
367 140 99
|
O-ring |
1 |
InternBDB: 160x5B NB90 | InternKon: 650 470 40 / 16
|
|
|
|
? |
007 632 98
|
O-ring |
1 |
InternBDB: 239,3x5,7B NB 90 | InternKon: 650 470 40 / 14
|
|
|
|
? |
226 431 40
|
Support ring |
1 |
InternBDB: Prдdifa P 240x250x 1-PTFE | InternKon: 650 470 40 / 15
|
|
|
|
? |
319 353 99
|
Screw |
20 |
InternBDB: M24x130/912 10.9 | InternKon: 650 470 40 / 19
|
|
|
|
? |
445 356 40
|
Sealing flange
consist. of fig-nos: 20 and 21
(finish work after bush
is installed) |
1 |
InternKon: 650 470 40 / 3
|
|
|
|
? |
445 353 40
|
Bush |
1 |
InternKon: 445 356 40 / 1
|
|
|
|
? |
445 354 40
|
Bush |
1 |
InternKon: 445 356 40 / 2
|
|
|
|
? |
342 689 99
|
Circlip |
1 |
InternBDB: 185x4 /472 | InternKon: 445 356 40 / 3
|
|
|
|
? |
440 150 40
|
Gasket, rod |
1 |
InternBDB: 160x180x14,5 BD 042 0160 | InternKon: 630 375 40 / 11
|
|
|
|
? |
440 149 40
|
Oil ring |
1 |
InternBDB: 160x172x10 A1U 28 G 010 | InternKon: 630 375 40 / 12
|
|
|
|
? |
354 389 99
|
Feather key |
1 |
InternBDB: A20x12x70/ 6885 | InternKon: 630 375 40 / 18
|
|
|
|
? |
764 762 73
|
Piston rod assy. consist. of
fig-no: 04-06 and 28 |
1 |
InternBDB: E-St
|
|
|
|
? |
|
Piston rod
These parts are not sold
separately |
1 |
InternBDB: 425 455 40 | InternKon: 630 375 40 / 2
|
|
|
|
? |
324 312 40
|
Shim |
-2 |
|
|
|
|
? |
695 882 73
|
Sealing kit for piston rod
consist. of fig.no. 10-15 |
-2 |
InternBDB: E-St
|
|
|
|
? |
697 568 73
|
Sealing kit for piston rod
consist. of fig-nos:
16, 17, 23 and 24 |
-2 |
InternBDB: E-St
|
|
