Diagram image 1 of 2

PC8000-11 S/N 12117

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC8000-11 S/N 12117

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?		See page Coolant preheating arr.	2
?	958 117 40	Console	4
?	962 007 40	Clamp retainer	1
?	995 101 40	Sheet metal	2
?		Hose assy.	1
?		Hose assy.	1
?		Hose assy.	1
?		Hose assy.	1
?		Hose assy.	1
?		Hose assy.	1
?	501 584 98	Weld on plate	8
?	504 989 98	Screw	8
?	534 008 99	Cover plate	2
?	504 990 98	Locking plate	4
?	512 053 98	Grommet	2
?	509 059 98	Clamp set	14
?	506 371 98	Clamp set	2
?	490 020 40	Clamp	1
?	0443452711	Clamp	2
?	907 415 40	Seal	4
?	950 526 40	Socket	4
?	305 991 99	Ball cock	4
?	551 345 40	Union	4
?	374 409 99	Socket	2
?	374 439 99	Socket	4
?	516 160 98	Socket	2
?	516 161 98	Socket	4
?	516 281 98	Socket	2
?	516 187 98	Socket	4
?	518 022 98	Union	4
?	334 599 99	Nut	2
?	507 037 98	Nut	2
?	334 600 99	Nut	12
?	307 754 99	Bolt	2
?	307 775 99	Bolt	4
?	307 800 99	Bolt	8
?	307 805 99	Bolt	8
?	308 615 99	Bolt	4
?	319 135 99	Screw	20
?	907 854 40	Thread pin	2
?	517 122 98	Lock washer	4
?	517 118 98	Lock washer	8
?	340 507 99	Washer	2
?	340 465 99	Washer	2
?	512 545 98	Washer	14
?		Hose assy.	1
?		Hose assy.	1
?		Hose assy.	1
?		Hose assy.	1
?	951 746 40	Magnet valve	2
?	307 679 99	Bolt	4
?	518 560 98	Lock washer	4
?	951 881 40	Radiator hose	2
?	374 925 99	Clamp	8
?	986 686 40	Socket	4
?	517 056 98	Union	2
?	551 404 40	Union	2
?	516 159 98	Socket	4

Komatsu PC8000-11 S/N 12117 parts catalog PDF

TEMPERATURE CONDITIONING - ENGINE COOL WATER-RESVERVE цLTANK-DEF TANK (213-2510) in PC8000-11 S/N 12117. Diagram image and parts list.
