|$0 |
723-57-21103
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping |
1 |
SN: 35820-@
|
|
|
|
|$1 |
723-57-21101
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve,1-Additional Actuator Piping |
1 |
SN: 35724-35819 | SCC: A2
|
|
|
|
|$2 |
|
Body Group |
1 |
SN: 35724-35924 | SCC: C1
|
|
|
|
1 |
|
Block |
1 |
SN: 35724-@ | SCC: C1
|
|
|
|
2 |
|
Spool |
1 |
SN: 35724-@ | SCC: C1
|
|
|
|
3 |
723-56-31970
|
Spring |
1 |
SN: 35724-@
|
|
|
|
4 |
|
Orifice |
1 |
SN: 35724-35924 | SCC: C1
|
|
|
|
5 |
|
Orifice |
1 |
SN: 35724-35924 | SCC: C1
|
|
|
|
6 |
|
Seal |
2 |
SN: 35724-35924 | SCC: C1
|
|
|
|
7 |
|
O-ring |
1 |
SN: 35724-35924 | SCC: C1
|
|
|
|
8 |
07002-11223
|
O-ring |
1 |
SN: 35724-35924
|
|
|
|
9 |
723-56-31940
|
Flange |
1 |
SN: 35724-@
|
|
|
|
10 |
723-11-18430
|
O-ring |
1 |
SN: 35724-35924
|
|
|
|
11 |
07000-11008
|
O-ring |
1 |
SN: 35724-35924
|
|
|
|
12 |
01252-60825
|
Bolt, Hexagon Socket Head |
2 |
SN: 35724-@
|
|
|
|
13 |
|
Valve |
2 |
SN: 35724-@ | SCC: C1
|
|
|
|
14 |
723-56-34860
|
Spring |
2 |
SN: 35724-@
|
|
|
|
|$17 |
|
[A2]-The part specified in the line above can be used instead of this part. |
-1 |
SN: UP
|
|
|
|
|$18 |
|
[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly. |
-1 |
SN: UP
|
|
