|$0 |
720-2G-00013
|
Pump Assembly |
1 |
SN: 46308-46683
|
|
|
|
|$1 |
720-2G-00012
|
Pump Assembly |
1 |
SN: 45067-46307 | SCC: B1
|
|
|
|
|$2 |
720-2G-00011
|
Pump Assembly |
1 |
SN: 40387-45066 | SCC: A2
|
|
|
|
|$3 |
720-2G-00010
|
Pump Assembly |
1 |
SN: 40001-40386 | SCC: A2
|
|
|
|
|$4 |
|
Pump Subassembly |
1 |
SN: 46308-46683 | SCC: C1
|
|
|
|
|$5 |
|
Pump Subassembly |
1 |
SN: 45067-46307 | SCC: C1
|
|
|
|
|$6 |
|
Pump Subassembly |
1 |
SN: 40387-45066 | SCC: C1
|
|
|
|
|$7 |
720-2G-01010
|
Pump Subassembly |
1 |
SN: 40001-40386 | SCC: C2
|
|
|
|
1 |
720-2G-12111
|
Shaft, Front |
1 |
SN: 46308-46683 | SCC: C2
|
|
|
|
|$9 |
720-2G-12110
|
Shaft, Front |
1 |
SN: 40001-46307 | SCC: C2
|
|
|
|
2 |
708-2G-12252
|
Bearing |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
3 |
708-2G-05010
|
Washer Kit |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
|$12 |
|
Washer, T=3.0mm |
1 |
SN: 40001-46683 | SCC: C1
|
|
|
|
|$13 |
|
Washer, T=3.1mm |
1 |
SN: 40001-46683 | SCC: C1
|
|
|
|
|$14 |
|
Washer, T=3.2mm |
1 |
SN: 40001-46683 | SCC: C1
|
|
|
|
4 |
708-1F-12270
|
Ring, Snap |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
5 |
720-2G-12320
|
Cover |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
6 |
708-2G-12230
|
Seal, Oil |
1 |
SN: 40001-46683
|
|
|
|
7 |
04065-01054
|
Ring, Snap |
1 |
SN: 40001-46683
|
|
|
|
8 |
07000-A2095
|
O-ring |
1 |
SN: 40001-46683
|
|
|
|
|$20 |
720-2G-04310
|
Block Assembly, Front |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
9 |
|
Cylinder Block |
1 |
SN: 40001-46683 | SCC: C1
|
|
|
|
10 |
|
Plate, Valve |
1 |
SN: 40001-46683 | SCC: C1
|
|
|
|
11 |
708-18-13230
|
Pin |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
12 |
04065-05520
|
Ring, Snap |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
13 |
708-2G-13131
|
Seat |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
14 |
708-2G-13152
|
Spring |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
15 |
708-2G-13141
|
Seat |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
16 |
708-2G-13510
|
Guide, Retainer |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
17 |
708-2H-23360
|
Pin |
3 |
SN: 40001-46683 | SCC: C2
|
|
|
|
18 |
708-2G-13341
|
Retainer, Shoe |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
19 |
708-2G-13370
|
Piston Subassembly |
9 |
SN: 40001-46683 | SCC: C2
|
|
|
|
|$32 |
|
[A2]-The part specified in the line above can be used instead of this part. |
-1 |
SN: UP
|
|
|
|
|$33 |
|
[B1]-This shows discontinued part. The part specified in the above line is supplied instead. |
-1 |
SN: UP
|
|
|
|
|$34 |
|
[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly. |
-1 |
SN: UP
|
|
|
|
|$35 |
|
[C2]-This part is supplied for authorized Komatsu distributors only. It cannot be supplied as an individual part. It is supplied as an assembly. |
-1 |
SN: UP
|
|
