|$0 |
720-2G-00013
|
Pump Assembly |
1 |
SN: 46308-46683
|
|
|
|
|$1 |
720-2G-00012
|
Pump Assembly |
1 |
SN: 45067-46307 | SCC: B1
|
|
|
|
|$2 |
720-2G-00011
|
Pump Assembly |
1 |
SN: 40387-45066 | SCC: A2
|
|
|
|
|$3 |
720-2G-00010
|
Pump Assembly |
1 |
SN: 40001-40386 | SCC: A2
|
|
|
|
|$4 |
|
Pump Subassembly |
1 |
SN: 46308-46683 | SCC: C1
|
|
|
|
|$5 |
|
Pump Subassembly |
1 |
SN: 45067-46307 | SCC: C1
|
|
|
|
|$6 |
|
Pump Subassembly |
1 |
SN: 40387-45066 | SCC: C1
|
|
|
|
|$7 |
720-2G-01010
|
Pump Subassembly |
1 |
SN: 40001-40386 | SCC: C2
|
|
|
|
|$8 |
720-2G-03130
|
Cover Assembly, Front |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
1 |
720-2G-14210
|
Cover |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
2 |
720-2M-14170
|
Screw |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
3 |
07000-B1010
|
O-ring |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
4 |
01582-11210
|
Nut |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
5 |
07000-A2090
|
O-ring |
2 |
SN: 40001-46683 | SCC: C2
|
|
|
|
6 |
01582-11210
|
Nut |
1 |
SN: 40001-46683 | SCC: C2
|
|
|
|
7 |
01252-61030
|
Bolt, Hexagon Socket Head |
8 |
SN: 40001-46683 | SCC: C2
|
|
|
|
|$16 |
|
[A2]-The part specified in the line above can be used instead of this part. |
-1 |
SN: UP
|
|
|
|
|$17 |
|
[B1]-This shows discontinued part. The part specified in the above line is supplied instead. |
-1 |
SN: UP
|
|
|
|
|$18 |
|
[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly. |
-1 |
SN: UP
|
|
|
|
|$19 |
|
[C2]-This part is supplied for authorized Komatsu distributors only. It cannot be supplied as an individual part. It is supplied as an assembly. |
-1 |
SN: UP
|
|
