D61PX-24 S/N 48001-UP

Komatsu parts book diagram for D61PX-24 S/N 48001-UP: HYDRAULIC PUMP, HST PUMP (6/11)(#46684-)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	720-2G-00030	Pump Assembly	1	SN: 46684-UP
	?		Pump Subassembly	1	SN: 46684-UP \| SCC: C1
	?	720-2G-04150	Case Assembly, Rear	1	SN: 46684-UP \| SCC: C2
	?		Case, Rear	1	SN: 46684-UP \| SCC: C1
	?		Plug, Stocking	25	SN: 46684-UP \| SCC: C1
	?	07044-12412	Plug	1	SN: 46684-UP
	?	07002-62434	O-ring	1	SN: 46684-UP
	?	01010-62095	Bolt	2	SN: 46684-UP \| SCC: C2
	?	01643-32060	Washer	2	SN: 46684-UP \| SCC: C2
	?	07000-B1009	O-ring	2	SN: 46684-UP
	?	07000-B2012	O-ring	3	SN: 46684-UP
	?	07000-B2022	O-ring	1	SN: 46684-UP
	?	04020-01228	Pin, Dowel	1	SN: 46684-UP \| SCC: C2
	?	04020-01434	Pin, Dowel	1	SN: 46684-UP \| SCC: C2
	?	708-1L-29340	Orifice	2	SN: 46684-UP \| SCC: C2
	?		[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP
	?		[C2]-This part is supplied for authorized Komatsu distributors only. It cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP

Komatsu D61PX-24 S/N 48001-UP parts catalog PDF

HYDRAULIC PUMP, HST PUMP (6/11)(#46684-) (H0210-001006A) in D61PX-24 S/N 48001-UP. Diagram image and parts list.
