500 |
768 459 73
|
Brake assy. |
1 |
InternBDB: L & S GFY 300 A 1041 / 203 720
|
|
|
|
501 |
757 361 73
|
Disc carrier |
1 |
InternBDB: 1/0579/9287/2
|
|
|
|
502 |
763 744 73
|
Piston |
1 |
InternBDB: 2/0575/9018/3
|
|
|
|
503 |
757 257 73
|
Ring |
1 |
InternBDB: 4/0403/9308/1
|
|
|
|
504 |
757 362 73
|
Pressure plate |
1 |
InternBDB: 4/0401/9369/0
|
|
|
|
506 |
768 455 73
|
Internal disc |
6 |
InternBDB: 103101 3/0539/9036/0
|
|
|
|
507 |
968 524
|
Outer disc |
7 |
InternBDB: 3/0531/9004/0
|
|
|
|
508 |
963 624
|
Compression spring |
36 |
InternBDB: 2,5x11,5x54 /2098
|
|
|
|
509 |
806 036 73
|
Compression spring |
18 |
InternBDB: 1,6x6,5x54 /2098
|
|
|
|
510 |
502 169 98
|
O-ring |
1 |
InternBDB: 250x3 /3771
|
|
|
|
511 |
972 122
|
O-ring |
1 |
InternBDB: 280x3 /3771
|
|
|
|
512 |
972 111
|
O-ring |
1 |
InternBDB: 270x3 /3771
|
|
|
|
513 |
342 702 99
|
Circlip |
1 |
InternBDB: 250x5 /472
|
|
|
|
514 |
342 701 99
|
Circlip |
1 |
InternBDB: 240x5 /472
|
|
|
|
515 |
513 534 98
|
Radial seal |
2 |
InternBDB: 100x125x12 B 1 /3760 461 235
|
|
|
|
516 |
768 080 73
|
Plug |
1 |
InternBDB: 469 003 GPN 300 F18
|
|
|
|
517 |
968 525
|
Quadring |
1 |
InternBDB: 461527 Busak 4370 446 A
|
|
|
|
518 |
968 526
|
Support ring |
2 |
InternBDB: 461556 210x219,4x1,4 P
|
|
|
|
519 |
968 527
|
Quadring |
1 |
InternBDB: 4373 446 A
|
|
|
|
520 |
765 546 73
|
Support ring |
2 |
InternBDB: 461551 232,5x242x1,4 P
|
|
|
|
521 |
313 267 99
|
Plug |
3 |
InternBDB: M22x1,5 /910
|
|
|
|
522 |
339 907 99
|
Seal ring |
5 |
InternBDB: A 22x27x1,5 /7603
|
|
