AIR CONDITIONING PIPING & INSTALLATION | AFE32-FA 830E COLLAHUASI

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE32-FA 830E COLLAHUASI

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EF3540	MOUNT, CONDENSER	1
?	PB9510	CONDENSER	1
?	TG5720	CAPSCREW - 3/8" - 16NC X 1"	6
?	TC1232	FLATWASHER - 3/8" (HARDENED)	14
?	TG9225	LOCKNUT - 3/8"	6
?	VY9850	MOUNT, RUBBER	4
?	DA0557	FLAT WASHER	8
?	C1615	CAPSCREW - 1/2" - 13NC X 1 3/4"	4
?	HA7185	HOSE - DISCHARGE	1
?	WA1732	O-RING	2
?	HA7166	HOSE	1
?	WA1731	O-RING	6
?	HA7167	HOSE	1
?	WA1733	O-RING	4
?	PB9351	ADAPTOR	1
?	PB9353	NUT, JAM	1
?	PB9352	ADAPTOR	1
?	PB9354	NUT, JAM	1
?	TN9748	HOSE, DRAIN	2
?	VP4693	GROMMET	2
?	HA7175	HOSE	1
?	HA7174	HOSE	1
?	WA0720	FLAT WASHER - 3/8"	50
?	VN2997	WELD STUD - 3/8" - 16NC X 1 1/4"	47
?	TF6925	CLAMP	61
?	C1521	NUT - 3/8" - 16NC	76
?	VN9913	CLAMP	40
?	HA7169	HOSE	1
?	TG2568	CLAMP	3
?	892124C1	SPACER	1
?	TC1234	CAPSCREW - 3/8" - 16NC X 3/4"	2
?	C1604	CAPSCREW - 3/8" - 16NC X 1 1/2"	1
?	PB8689	RECEIVER, DRIER	1
?	PB2216	BRACKET, DRIER	1
?	PB7620	SWITCH, PRESSURE	1
?	PB7619	ADAPATOR	1
?	WA0192	WELD STUD - 1/4" - 20NC X 3/4"	2
?	C5774	LOCKWASHER - 1/4"	2
?	C5780	NUT - 1/4" - 20NC	2
?	EF5362	CHANNEL, L.H.	1
?	EF5360	CHANNEL, R.H.	1
?	VN9027	CAPSCREW - 1/2" - 13NC X 7/8"	4
?		NOTE: NS = NOT SHOWN	65535
?	EF3874	HARNESS, A/C	1
