HEATER/AIR CONDITIONER (PB8386/PB8388) | AFE32-FA 830E COLLAHUASI

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE32-FA 830E COLLAHUASI

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VE9793	COVER ASSEMBLY (1)	1
?		SEAL - NEOPRENE 20. 1/8" - N.S.S. (1)/(3)	1
?	VE9764	CORE, HEATER (1)	1
?	VE9762	LOUVER ASSEMBLY (1)	1
?	VE9765	NUT - PUSH (1)	2
?	VE9792	CLIP, CABLE (1)	2
?	VE9778	CASE (1)	1
?	VE9767	GROMMET (1)	1
?	VE9771	PLUG (1)	1
?	VE9768	ELBOW (1)	2
?	VE9790	SUPPORT, BLOWER ASSEMBLY (1)	1
?	VE9781	HEAT SINK (1)	1
?		SEAL - NEOPRENE - 1.68 FT. - N.S.S. (1)/(3)	1
?	VE9787	FOIL (1)	2
?	VE9782	WHEEL, BLOWER (1)	1
?	VE9784	STRAP (1)	1
?	VE9791	NUT (1)	1
?	VE9786	HOUSING, BLOWER (1)	1
?	VE9789	RESISTOR, 24V (1)	1
?	VE9783	INSULATOR, MOTOR (1)	1
?	VE9763	HARNESS (1)	1
?	VE9772	PLUG (1)	1
?		SEAL - NEOPRENE - 1.4 FT. - N.S.S. (1)/(3)	2
?	VE9773	PLUG (1)	1
?	VE9788	MOTOR, BLOWER ASSEMBLY (1)	1
?	VE9785	WHEEL, BLOWER (1)	1
?		FILTER, FOAM - 1.35 FT. - N.S.S. (1)	1
?	VE9794	PLATE, CONNECTION (1)	1
?	BF0096	CORE, EVAPORATOR (2)	1
?	BF0097	VALVE, EXPANSION (2)	1
?	BF0098	TUBE ASSEMBLY (2)	1
?	BF0099	TUBE ASSEMBLY (2)	1
?	BF0102	O-RING	1
?	BF0103	O-RING	2
?	BF0104	O-RING	1
?	BF3203	SWITCH, THERMOSTATIC (A/C)	1
?		NOTE: (1) INCLUDED IN PB8385 HEATER ASSEMBLY.	65535
?		(2) INCLUDED IN PB8388 AIR CONDITIONER ASSM.	65535
?		(3) NOT SVCD SEPARATELY.	65535
