ENGINE WIRING | AFE47-AD 730E SISHEN (A30095 & A30098)

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-AD 730E SISHEN (A30095 & A30098)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	PB8887	SENSOR, COOLANT TEMPERATURE	1
?	TG2562	CLAMP	7
?	VH9969	WELD STUD - 3/8" - 16NC X 3/4"	12
?	C1547	FLAT WASHER - 3/8"	13
?	C0312	LOCKWASHER - 3/8"	19
?	C1521	NUT - 3/8" - 16NC	12
?	PC0119	SEAL, ADAPTOR	2
?	PC0122	ADAPTOR - METRIC TO JIC	1
?	WB0359	FITTING, STRAIGHT ADAPTOR	1
?	720462	CLAMP	8
?	MM0641	WELD STUD - M8 X 20	3
?	MM0470	LOCKWASHER - M8	3
?	MM0460	FLAT WASHER - M8	3
?	MM0177	NUT - M8 X 1.25	3
?	VW5097	HOSE	1
?	LW00351	LOOM - 63"	1
?	LW00551	LOOM - 12"	1
?	LW30651	TAPE - #33 - 18"	1
?	EG5419	HARNESS, EXTERNAL 4000	1
?	EG7534	BRACKET, CONNECTOR	1
?	TC4830	MACHINE SCREW - #6 - 32NC X 5/8"	2
?	DF4944	LOCKWASHER - #6	4
?	DD2468	NUT - #6 - 32NC	2
?	LW42651	SLEEVE, SHRINK - 2 1/4"	1
?	TY8239	CONNECTOR	1
?	MM0583	CAPSCREW - M6 X 1.00 X 25	2
?	MM0459	FLAT WASHER - M6	2
?	EF2654	ALTERNATOR, BATTERY CHARGING (SEE INDEX)	1
?	TN0689	CABLE	1
?	EG5421	WIRE	1
?	TC1234	CAPSCREW - 3/8" - 16NC X 3/4"	1
?	MM0469	LOCKWASHER - M6	2
?	PC0205	SENDER, TEMPERATURE	1
?	ED4696	COVER, ALTERNATOR OUTLET	1
?	TD1541	SETSCREW - 1/4" - 20NC X 3/4"	4
?		NOTE: NS = NOT SHOWN	65535
?	VN5153	WIRE, CROUND - SUB-FRAME TO L.H. FRAME RAIL	1
?	MM0026	CAPSCREW - M8 X 1.35 X 25	2
?	MM0712	FLAT WASHER - M8	2
?	MM0470	LOCKWASHER - M8	2
