CAB INTERFACE COMPARTMENT | AFE47-FH 730E S/N A30524 NITTETSU

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-FH 730E S/N A30524 NITTETSU

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	C1676	CAPSCREW - 7/16" - 20NF X 1 1/2"	2
?	TD0795	LOCKWASHER - 7/16"	2
?	EJ8296	BASE, COMPONENTS	1
?	SM5926	LIGHTER, CIGAR - 12 VOLT	1
?	SC5252	MACHINE SCREW - #8 - 32NC X 3/4"	1
?	VM9910	LOCKWASHER - #8	1
?	TV2179	NUT - #8 - 32NC	1
?	VE2894	BEZEL	1
?	SM0550	PANEL, SHIFT CONSOLE	1
?	VE2590	TRAY, ASH	1
?	SM5110	SENSOR, ANGLE (INCLINOMETER) (1)	1
?	VC8762	CAPSCREW - 3/8" - 16NC X 1 1/2" (1)	3
?	TR4436	FLAT WASHER - 3/8" (1)	3
?	TC1231	LOCKWASHER - 3/8" (1)	3
?	TC1233	NUT - 3/8" - 16NC (1)	3
?	PB8639	SWITCH, ROCKER	2
?	TF7982	GROMMET, RUBBER	1
?	PB8624	SWITCH, PUSH BUTTON	1
?	PB6343	BUTTON, PLUG	1
?	PB4060	SWITCH, PUSH BUTTON	1
?	PB6503	SWITCH, PUSH PULL	1
?	PB5957	KNOB	1
?	ED2863	POTENTIOMETER	1
?	TY8745	SWITCH, CONTROL	1
?	WA4513	SCREW, SELF TAPPING - #10 - 24NC X 1/2"	9
?	TZ7321	PLATE, NAME - LICLU	1
?	MM0593	CAPSCREW - M8 X 1.25 X 20	10
?	MM0470	LOCKWASHER - M8	15
?	SM2224	SEAL, STRIP	1
?	SM0887	COVER, COMPONENTS BASE	1
?	SM2223	SEAL, STRIP	1
?		HARNESS, SHIFT TOWER (2)	1
?	SM2222	SEAL, STRIP	2
?	SM2826	SEAL, STRIP	1
?	SM2463	SEAL, STRIP	1
?	SM2827	SEAL, STRIP	1
?	SM2324	SEALANT	1
?		HARNESS, BUDDY SEAT INTERNAL (2)	1
?	MM0016	CAPSCREW - M8 X 1.25 X 16	3
?	MM0460	FLAT WASHER - M8	3
?	TF6925	CLAMP, VINYL - 3/4"	3
?	SM5278	PLATE, BENT	1
?	MM0019	CAPSCREW - M6 X 1.00 X 16	2
?	MM0469	LOCKWASHER - M6	2
?	MM0459	FLAT WASHER - M6	2
?		HARNESS, AID MODULE (2)	1
?	PC1810	AID MODULE ASSEMBLY (SEE INDEX)	1	55673
?	MM0582	CAPSCREW - M6 X 1.00 X 20	4
?	MM0469	LOCKWASHER - M6	4
?	TZ7319	PLATE, NAME - RD1	1
?	TZ7320	PLATE, NAME - RD2	1
?	MM0718	NUT - M8 X 1.25	1
?	MM0711	FLAT WASHER - M6	4
?	PC0040	CARD, OIL LEVEL TEMPERATURE	1
?	VJ9025	CARD, DUAL HOT SWITCH INVERTER	1
?	PB8624	SWITCH, PUSH BUTTON	1
?	SM0628	COVER	1
?	HE2467	MACHINE SCREW - #6 - 32NC X 1/2"	2
?	HE5125	FLAT WASHER - #6	4
?	DF4944	LOCKWASHER - #6	2
?	DD2468	NUT - #6 - 32NC	2
?	EG4513	HARNESS (DATA STORE)	1
?		NOTE: (1) INCLUDED IN PLM III OPTION.	-1
?		(2) ALL SUPPLIED AS EH7497 BUDDY SEAT	-1
?		AREA HARNESS.	-1
