AFE47-FH 730E S/N A30524 NITTETSU

Komatsu parts book diagram for AFE47-FH 730E S/N A30524 NITTETSU: LIGHT ASSEMBLY (SUPER HALOGEN)

? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	AK7551	FLANGE HOUSING	1
	?	AK4236	BULB, LIGHT - 24V/100W (1)/(2)	1
	?	AK7575	BULB, LIGHT - 24V/65W (3)	1
	?	AK7554	SPRING, BULB RETAINER (MULTIPAK 10)	1
	?	AK3335	LENS/REFLECTOR - HIGH BEAM (WITHOUT BULB) (1)	1
	?	AK3341	LENS/REFLECTOR - HIGH BEAM (WITH BULB) (1)	1
	?	AK3336	LENS/REFLECTOR - LOW BEAM (WITHOUT BULB) (2)	1
	?	AK3342	LENS/REFLECTOR - LOW BEAM (WITH BULB) (2)	1
	?	AK7541	LENS/REFLECTOR - FOG - AMBER (WITHOUT BULB) (3)	1
	?	AK7549	LENS/REFLECTOR - FOG - AMBER (WITH BULB) (3)	1
	?	AK7556	GASKET (MULTIPAK 10)	1
	?	AK7559	BEZEL	1
	?	AK7561	SCREW (MULTIPAK 30)	3
	?		NOTE: (1) INCLUDED IN AK3332 HEADLIGHT ASSM. (HIGH BEAM)	-1
	?		(2) INCLUDED IN AK3333 HEADLIGHT ASSM. (LOW BEAM)	-1
	?		(3) INCLUDED IN AK7530 FOGLIGHT ASSM. (OPTIONAL)	-1
	?		(ALL PARTS ARE COMMON, EXCEPT WHERE INDICATED.)	-1
