AFE48-AT 930E-2 S/N A30122-A30127 & A30130 BARRICK GOLDSTRIKE

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	GE0243	SET, LABEL - (CT-R1)	1
?	GE0244	SET, LABEL - (A3PV-GFC0)	1
?	GE0245	SET, LABEL - (AXFU11-RTNBUS)	1
?	GE0209	SET, LABEL - (DCN1BUS-RDBUSAC3)	1
?	BF3909	SET, LABEL - (REST MODE - TEST MODE)	1
?	GE0248	SET, LABEL - (INVERTER #1 - INVERTER #2)	1
?	GE0249	LABEL, CHART RECORDER	1
?	GE0250	SET, LABEL - (NORMAL CUTOUT - ON - OFF)	1
?	BF3910	LABEL, G.F.C.	1
?	GE0252	LABEL, ECT	1
?	BF3911	PIN, COTTER	8
?	VJ8249	MACHINE SCREW - #8 - 36NF X 3/4" (FILISTER HEAD)	4
?	GE0255	MACHINE SCREW - #10 - 32NC X 7/16" (HEX HEAD)	2
?	VJ9161	MACHINE SCREW - #10 - 32NC X 1/2" (HEX HEAD)	1
?	VJ6586	MACHINE SCREW - #10 - 32NC X 3/4" (HEX HEAD)	8
?	VE4921	MACHINE SCREW - #10 - 32NC X 1" (HEX HEAD)	6
?	GE0256	MACHINE SCREW - #10 - 32NC X 1 7/8" (HEX HEAD)	4
?	C5746	CAPSCREW - 1/4" - 20NC X 3/4"	12
?	VE5882	CAPSCREW - 1/4" - 20NC X 7/8"	-1
?	BF0699	CAPSCREW - 5/16" - 18NC X 3/4"	12
?	VE4349	CAPSCREW - 5/16" - 18NC X 7/8"	4
?	BF3889	CAPSCREW - 5/16" - 18NC X 1"	4
?	VE4641	CAPSCREW - 3/8" - 16NC X 1 1/4"	-1
?	VE4640	CAPSCREW - 3/8" - 16NC X 1 1/2"	10
?	GE0257	CAPSCREW - 3/8" - 16NC X 1 7/8"	10
?	GE0256	CAPSCREW - 1/2" - 13NC X 1 3/8"	5
?	VE4518	CAPSCREW - 1/2" - 13NC X 1 1/2"	12
?	VE4999	CAPSCREW - 1/2" - 13NC X 2"	3
?	GE0259	CAPSCREW - 1/2" - 13NC X 2 1/8"	12
?	C1620	CAPSCREW - 1/2" - 13NC X 3"	4
?	VE6232	CAPSCREW - 1/2" - 13NC X 3 1/4"	-1
?	VE4992	CAPSCREW - 5/8" - 11NC X 1 3/4"	2
?	VE4604	FLAT WASHER - #8 (NARROW)	4
?	VS6662	FLAT WASHER - #10 (NARROW)	3
?	VE4655	FLAT WASHER - #10	-1
?	VE7202	FLAT WASHER - 1/4" (NARROW)	-1
?	BF3890	FLAT WASHER - 5/16" (NARROW) STAINLESS STEEL	-1
?	VE4648	FLAT WASHER - 5/16"	-1
?	VE4516	FLAT WASHER - 3/8" (NARROW)	-1
?	VE4515	FLAT WASHER - 3/8"	-1
?	VE4490	FLAT WASHER - 1/2" (NARROW)	-1
?	VE4519	FLAT WASHER - 1/2" (NARROW)	-1
?	VE5169	FLAT WASHER - 5/8"	-1
?	VE4606	LOCKWASHER - #8	4
?	VC1390	LOCKWASHER - #10	-1
?	DC3584	LOCKWASHER - 1/4"	-1
?	BF3891	LOCKWASHER - 5/16" STAINLESS STEEL	-1
?	VE4687	LOCKWASHER - 3/8"	-1
?	VE4699	LOCKWASHER - 1/2"	-1
?	VE5171	LOCKWASHER - 5/8"	-1
?	SF2755	NUT - #10 - 32NF	-1
?	VE4481	NUT - 1/4" - 20NC SELF LOCKING	-1
?	VE5013	NUT - 5/16" - 18NC	-1
?	TC1233	NUT - 3/8" - 16NC	-1
?	VE4698	NUT - 1/2" - 13NC	-1
?	GE0045	NUT - 5/8" - 11NC	-1
?	GE0209	SET, LABEL (DCN1BUS-RDBUSAC3)	1
?		NOTE: NS = NOT SHOWN	-1
?	VE8185	CEMENT	-1
?	VE7272	SEALANT (TRANSLUSCENT)	-1
?	GE0213	SEALING COMPOUND	-1

Komatsu AFE48-AT 930E-2 S/N A30122-A30127 & A30130 BARRICK GOLDSTRIKE parts catalog PDF

HARDWARE, DECAL & MISCELLANEOUS (64031) in AFE48-AT 930E-2 S/N A30122-A30127 & A30130 BARRICK GOLDSTRIKE. Diagram image and parts list.
