AFE48-DP 930E-2 S/N A30298 & A30299 TRANSALTA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EJ4164	BOX, BATTERY	1
?	EF9621	PLATE, BENT	2
?	MM0471	LOCKWASHER - M10	13
?	MM0604	CAPSCREW - M10 X 1.50 X 20	13
?	EG9147	LID, BATTERY BOX	2
?	TR8320	MACHINE SCREW	16
?	EJ6707	CLAMP, HOLDDOWN	2
?	561-06-A4130	CLAMP, HOLDDOWN	4
?	561-06-A4140	ROD, HOLDDOWN	8
?	561-06-A4160	ROD, HOLDDOWN	12
?	DC3101	LOCKWASHER - #10	16
?	PB9830	LATCH, BAIL HANDLE	8
?	VZ0852	BATTERY	4
?	EB3707	INSULATION, EDGING STRIP	3
?	EF9622	STRIP, SEAL - LID - SHORT SIDE	4
?	EF9623	STRIP, SEAL - LID - LONG SIDE	4
?	VD3390	BATTERY	2
?	CH4506	CABLE, BATTERY	1
?	CH4507	CABLE, BATTERY	1
?	CH4020	CABLE, BATTERY	1
?	CH4019	CABLE, BATTERY	1
?	CH3834	CABLE, BATTERY	1
?	CH3835	CABLE, BATTERY	1
?	CH3860	CABLE, BATTERY	1
?	CH4612	CABLE, BATTERY	1
?	CH4504	CABLE, BATTERY	1
?	TC1565	CLAMP	2
?	TV0177	FLAT WASHER - 5/16"	4
?	TD1684	NUT - 5/16"	3
?	TF6925	CLAMP	1
?	CH4431	CABLE, BATTERY	1
?	CH4619	CABLE, BATTERY	1
?	CH3861	CABLE, BATTERY	1
?	CH4018	CABLE, BATTERY	1
?	CH3832	CABLE, BATTERY	1
?	CH3833	CABLE, BATTERY	1
?	EG6812	CLAMP, HOLDDOWN	2
?	MM0693	NUT - M10 X 1.50	20
?	MM0713	FLAT WASHER - M10 (HARDENED)	20
?	TD0794	CAPSCREW - 5/16" 18NC X 3/4"	1
?	EG9131	CLAMP, HOLDDOWN	2
?	SC4174	LOCKWASHER - 5/16"	3
?	PC0291	STAND OFF, INSULATED	1
?	TR5445	LOCKWASHER - 1/2"	3
?	TR6008	FLAT WASHER - 1/2"	3
?	TR1376	CAPSCREW - 1/2" - 13NC X 1 1/4"	1
?	VL9602	CLAMP	1
?	EJ3891	CLAMP	7
?	TR6643	NUT - 1/2"	1
?	MM0461	FLAT WASHER - M10	7
?	VY8331	CLAMP	3
?	EJ3892	ROD, THREADED	1
?	MM0459	FLAT WASHER - M6	1
?	MM0176	NUT - M6 X 1.00	1
?		(EJ4167 BATTERY BOX IS NOT SERVICED AS AN ASSEMBLY.	-1
?		ORDER INDIVIDUAL COMPONENT PARTS.)	-1

Komatsu AFE48-DP 930E-2 S/N A30298 & A30299 TRANSALTA parts catalog PDF

BATTERY BOX ASSEMBLY (EJ4167) (60511) in AFE48-DP 930E-2 S/N A30298 & A30299 TRANSALTA. Diagram image and parts list.
