AUTOMATIC LUBRICATION SYSTEM - 1 | AFE52-J 930E-3 S/N A30336-A30340 KLEMKE

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE52-J 930E-3 S/N A30336-A30340 KLEMKE

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	TA4410	INJECTOR, FRONT (3 PIECE) (1)	2
?	XA2520	NIPPLE & CAP ASSEMBLY	6
?	VW7990	CAP, PROTECTIVE	6
?	WB0252	FITTING, ELBOW - 90 DEG	6
?	HA3159	HOSE (FRONT INJECTORS TO STRG CYLINDERS & TIE ROD ENDS)	4
?	HA0570	HOSE (FRONT INJECTORS TO STEERING CYLINDERS)	2
?	C5770	PLUG, PIPE - 3/8"	2
?	WB0262	FITTING, ELBOW - 90 DEG	2
?	HA5564	HOSE (R.H. FRONT INJECTOR TO JUNCTION AT HORSECOLLAR)	1
?	HA5769	HOSE (L.H. FRONT INJECTOR TO JUNCTION AT HORSECOLLAR)	1
?	MM0609	CAPSCREW - M10 X 1.50 X 45	4
?	MM0471	LOCKWASHER - M10	4
?	WB0574	FITTING, STRAIGHT	4
?	VN9907	CLAMP, VINYL - 5/8" I.D.	45
?	MM0648	STUD - M10 X 1.50 X 25	22
?	MM0471	LOCKWASHER - M10	50
?	MM0178	NUT - M10 X 1.50	50
?	TC6058	CLAMP, VINYL - 1 1/2" I.D.	12
?	WB0531	FITTING, ELBOW - 45 DEG	2
?	TF6925	CLAMP, VINYL - 3/4" I.D.	11
?	HA8248	HOSE (LUBE PUMP TO JUNCTION AT HORSECOLLAR)	1
?	HA7288	HOSE (REAR INJECTORS TO JUNCTION AT HORSECOLLAR)	1
?	WB0418	FITTING, TEE	1
?	WB0391	FITTING, TEE	1
?		NOTE: NS = NOT SHOWN	-1
?	VN9913	CLAMP, VINYL - 1 1/16" I.D.	2
?	WA4649	CLAMP, VINYL - 1 11/16" I.D.	3
?	TF6924	CLAMP, VINYL - 1 3/4" I.D.	2
?	TR9441	CLAMP, VINYL - 1 1/4" I.D.	10
?	VZ0598	TYRAP	15
?		NOTE: (1) FOR SINGLE INJECTOR, ORDER VS1947.	-1
