1
EM5415
HARNESS, ORBCOMM
1
2
PC1962
HARNESS, ORBCOMM (COAX)
1
3
EM8615
HARNESS, PLM III/AUXILIARY BOX
1
4
EK7547
HARNESS, VHMS
1
5
EM8299
HARNESS, INTERFACE MODULE CONNECTOR
1
5
421-06-11970
DIODE - 3 AMP (D13, D19, D22 - D24, D27, D30, D50, D56, D57, D59 - D63, D65 - D67, D74, D80 - D83)
23
5
58B-06-00120
RESISTOR - 2,000 OHM, 3W (R11, R15, R16)
3
5
58B-06-00290
VARISTOR (R17, R18, R23, R24, R42, R43, R45, R50, R55)
9
5
EK4129
RESISTOR - 750 OHM (R28)
1
6
EM8008
HARNESS, GE/AUX BOX INTERFACE
1
7
EM8242
HARNESS, AUXILIARY CONTROL CABINET INTERNAL
1
7
08020-10000
DIODE (D11, D15 - D18, D21, D33, D35, D49, D51 - D55, D69 - D71, D80, D85, LLD1)
20
7
EF6927
RESISTOR - 22,100 OHM (R7, R8)
2
7
58B-06-00120
RESISTOR - 2,000 OHM, 3W (R1 - R5, R10, R12, R13, R21)
9
7
PC2399
FUSE - 1 AMP
4
8
PC0616
RECEPTACLE, TEE
6
9
PC0618
PLUG, TERMINATING
3
10
EK5341
HARNESS, 1939 JUMPER
2
11
EK5340
HARNESS, 1939 JUMPER
2
NS|20
NOTE: NS = NOT SHOWN
-1
NS|21
CH5101
CABLE, BATTERY - BLACK (1)
1
NS|22
CH5001
CABLE, BATTERY - RED (1)
1
NS|23
EM8017
HARNESS, MODULAR MINING SYSTEM (2)
1
NS|24
58B-06-11000
WIRE, JUMPER - CIRCUIT 712 POWER
1
NS|25
NOTE: (1) TOP CORNER OF LEFT SIDE WALL.
-1
NS|26
(2) OPTIONAL FEATURE.
-1
