HOIST CYLINDER ASSEMBLY 58B-50-01010 | AFE75-B 980E-5 S/N A50006 - A50007 TECK

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE75-B 980E-5 S/N A50006 - A50007 TECK

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58B-50-01250	CYLINDER HEAD ASSEMBLY	1
?	58B-50-01260	HEAD	1
?	EL3415	QUILL ASSEMBLY	1
?	EL3414	QUILL	1
?	722187	POPPET, BALL	2
?	EB8590	PLUG	2
?	VM2202	PLUG, VENT	1
?	VN9097	CAPSCREW - 1" - 8NC X 2 3/4"	24
?	WA0364	FLAT WASHER, HARDENED - 1"	24
?	WA0458	O-RING (1)	1
?	WA1458	RING, BACKUP (1)	1
?	58B-50-01450	SNAP RING	1
?	58B-50-01470	BEARING - 12 5/8" (1)	2
?	58B-50-01310	SEAL - 12 5/8" (1)	1
?	TY1503	SEAL (1)	1
?	58B-50-01280	RETAINER, BEARING	1
?	WA1627	CAPSCREW - 7/8" - 9NC X 2 1/2"	10
?	58B-50-01480	BEARING - 15 1/8" (1)	2
?	58B-50-01320	SEAL - 15 1/8" (1)	1
?	58B-50-01460	BEARING - 10 1/8" (1)	2
?	58B-50-01300	SEAL - 10 1/8" (1)	1
?	58B-50-01020	HOUSING	1
?	58B-50-01070	TUBE - 14 1/8"	1
?	58B-50-01120	TUBE - 14 1/8"	1
?	58B-50-01170	ROD, PIVOT	1
?	58B-50-01410	BEARING - 14 1/8" (1)	1
?	58B-50-01440	SEAL, BUFFER - 14 1/8" (1)	1
?	58B-50-01400	SEAL, ROD - 14 1/8" (1)	1
?	58B-50-01390	SEAL, WIPER - 14 1/8" (1)	1
?	58B-50-01380	BEARING - 11 3/8" (1)	1
?	58B-50-01430	SEAL, BUFFER - 11 3/8" (1)	1
?	58B-50-01370	SEAL, ROD - 11 3/8" (1)	1
?	58B-50-01360	SEAL, WIPER - 11 3/8" (1)	1
?	58B-50-01350	BEARING - 7 5/8" (1)	1
?	58B-50-01420	SEAL, BUFFER - 7 5/8" (1)	1
?	58B-50-01340	SEAL, ROD - 7 5/8" (1)	1
?	58B-50-01330	SEAL, WIPER - 7 5/8" (1)	1
?	58B-50-01560	PLATE	1
?	58B-50-01490	SNAP RING	1
?	WA1443	RING, BACKUP (1)	2
?	WA0443	O-RING (1)	1
?	58B-HC-AK020	NOTE: (1) INCLUDED IN 58B-HC-AK020 REBUILD KIT.	-1
