STEERING SYSTEM PIPING 2/2 | AFE75-B 980E-5 S/N A50006 - A50007 TECK

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE75-B 980E-5 S/N A50006 - A50007 TECK

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	PC1493	BLEEDDOWN MANIFOLD (SEE INDEX)	1	61573
?	58B-60-10480	HOSE (RETURN FROM BLEEDDOWN MANIFOLD)	1
?	WB3094	CLAMP, CUSHIONED - 1 3/4"	2
?	TY8375	SPACER	5
?	TV1918	CAPSCREW - 1/2" - 13NC X 1 3/4"	12
?	MM0461	FLAT WASHER - M10	10
?	MM0178	NUT - M10 X 1.50	8
?	VH6718	CLAMP, SPLIT FLANGE - 2 1/2"	2
?	WB3855	CLAMP, CUSHIONED - 13/16"	10
?	VG9097	O-RING	1
?	58B-60-02380	HOSE	1
?	HA8703	HOSE (SUPPLY TO BLEEDDOWN MANIFOLD)	1
?	HA7687	HOSE	1
?	HA8218	HOSE (STEERING PUMP SUPPLY PORT)	1
?	WA0232	O-RING	1
?	58B-60-02580	HOSE (HOIST VALVE POWER UP)	1
?	58B-60-02560	HOSE (HOIST VALVE POWER DOWN)	1
?	TF8077	CLAMP, SPLIT FLANGE - 1"	2
?	TR5445	LOCKWASHER - 1/2"	12
?	WA5630	CLAMP, SPLIT FLANGE - 1 1/4"	4
?	VG9096	O-RING	4
?	TR4090	CAPSCREW - 7/16" - 14NC X 1 1/2"	8
?	TD0795	LOCKWASHER - 7/16"	8
?	TF3237	CLAMP, SPLIT FLANGE - 1 1/4"	4
?	TD0791	CAPSCREW - 3/8" - 16NC X 2 1/4"	4
?	TC1231	LOCKWASHER - 3/8"	4
?	WB3092	CLAMP, CUSHIONED - 7/8"	5
?	WB1300	CLAMP, CUSHIONED - 5/8"	3
?	WB1306	CLAMP, CUSHIONED - 2"	1
?	EK9920	BRACKET	1
?	MM0605	CAPSCREW - M10 X 1.50 X 25	2
