AFE75-M 980E-5 S/N A50044 - A50046, A50048 COPPER MOUNTAIN

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	GE0035	CLAMP, CABLE	6
?	GE0036	CLEAT, CABLE	6
?	VE4515	FLAT WASHER - 3/8"	22
?	VE4687	LOCKWASHER - 3/8"	22
?	GE0040	CAPSCREW - 3/8" - 16NC X 3 1/2"	2
?	XA3152	CAPSCREW - 3/8" - 16NC X 6"	2
?		MOTOR, BLOWER (SEE FIG 64000)	2	64000
?	GE0037	GROMMET	2
?	GE0479	INSULATOR	2
?	VE2338	CAPSCREW - 5/16" - 16NC X 3/4"	2
?	BF4421	CAPSCREW - 3/8" - 16NC X 1"	16
?	VE4519	FLAT WASHER - 1/2"	16
?	VE4699	LOCKWASHER - 1/2"	16
?	PB8167	CAPSCREW - 1/2" - 13NC X 6 1/2"	16
?	VE4698	NUT - 1/2" - 13NC	16
?	BF1888	FLAT WASHER - 1/2"	8
?	GE0023	INSULATOR W/BOLTS	48
?	XA2741	NUT - 5/8" - 11NC	48
?	GE0038	SPACER	48
?	GE0044	FLAT WASHER	48
?	GE0045	NUT - 5/8" - 11NC	96
?	VC1390	LOCKWASHER - 5/8"	96
?	GE0042	FLAT WASHER - 5/8"	48

Komatsu AFE75-M 980E-5 S/N A50044 - A50046, A50048 COPPER MOUNTAIN parts catalog PDF

RETARDING GRID 2/3 58B-06-03700 (61025) in AFE75-M 980E-5 S/N A50044 - A50046, A50048 COPPER MOUNTAIN. Diagram image and parts list.
