PC5500-6 S/N 15049

Komatsu parts book diagram for PC5500-6 S/N 15049: RETURN LINES - FAN MOTORS ( OIL COOLER )

? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	515 188 98	Hose assy.DN 32 x 2700	1	InternBDB: DOL 35 / FS 1 - 90 \| InternKon: 574 550 40 / 18
	?	324 524 40	Flange seal	3	InternBDB: 1 NBR 90 \| InternKon: 574 550 40 / 28
	?	047 326 40	Half flange	8	InternBDB: 25 / 420
	?	319 274 99	Bolt	12	InternBDB: M12x40 /912 10.9 \| InternKon: 574 550 40 / 45
	?	647 881 40	Hose assy.DN 25 x 1470	1	InternBDB: FS 1 / FS 1 - 90 \| InternKon: 574 550 40 / 17
	?	374 407 99	Socket	2	InternBDB: L 15 M /3901
	?	511 069 98	Hose assy.DN 12 x 1800	1	InternBDB: DOL 15 / DOL 15 - 90 \| InternKon: 574 550 40 / 19
	?	516 175 98	Socket	1	InternBDB: L 15 / 3944 \| InternKon: 574 550 40 / 24
	?	374 422 99	Socket	1	InternBDB: L 35 / 3901 \| InternKon: 574 550 40 / 55
	?	516 162 98	Socket	1	InternBDB: L 35 / 3942 \| InternKon: 574 550 40 / 56
	?	512 634 98	Hose assy.DN 12 x 5600	1	InternBDB: DOL 15 / DOL 15 \| InternKon: 913 585 40 / 34
	?	374 407 99	Union	1	InternBDB: L15 E-M / 3901 \| InternKon: 913 585 40 / 65
	?	516 158 98	Socket	1	InternBDB: L 15 / 3901 \| InternKon: 913 585 40 / 64

Komatsu PC5500-6 S/N 15049 parts catalog PDF

RETURN LINES - FAN MOTORS ( OIL COOLER ) (515-1818f) in PC5500-6 S/N 15049. Diagram image and parts list.
