01 |
922 837 40
|
Rail |
1 |
InternKon: 930 204 40 / 1
|
|
|
|
02 |
922 849 40
|
Rail |
1 |
InternKon: 930 204 40 / 6
|
|
|
|
03 |
937 594 40
|
Rail |
1 |
InternKon: 930 204 40 / 7
|
|
|
|
04 |
922 802 40
|
Rail |
1 |
InternKon: 930 204 40 / 8
|
|
|
|
05 |
931 176 40
|
Rail |
1 |
InternKon: 930 204 40 / 9
|
|
|
|
06 |
904 372 40
|
Rail |
1 |
InternKon: 930 204 40 / 10
|
|
|
|
07 |
931 179 40
|
Rail |
1 |
InternKon: 930 204 40 / 11
|
|
|
|
08 |
942 264 40
|
Rail |
1 |
InternKon: 930 204 40 / 22
|
|
|
|
09 |
942 273 40
|
Rail |
1 |
InternKon: 930 204 40 / 23
|
|
|
|
10 |
922 821 40
|
Rail |
1 |
InternKon: 930 204 40 / 24
|
|
|
|
11 |
930 214 40
|
Rail |
1 |
InternKon: 930 204 40 / 28
|
|
|
|
12 |
922 818 40
|
Rail |
1 |
InternKon: 930 204 40 / 45
|
|
|
|
13 |
308 605 99
|
Bolt |
8 |
InternBDB: M12x55 DIN00931 | InternKon: 930 204 40 / 25
|
|
|
|
14 |
510 744 98
|
Resilient sleeve |
8 |
InternKon: 930 204 40 / 26
|
|
|
|
15 |
307 802 99
|
Bolt |
2 |
InternBDB: M12x25 DIN00933 | InternKon: 930 204 40 / 13
|
|
|
|
16 |
343 054 99
|
Washer |
8 |
InternBDB: 13 DIN00463 | InternKon: 930 204 40 / 14
|
|
|
|
17 |
930 225 40
|
Rail |
1 |
InternKon: 930 204 40 / 16
|
|
|
|
18 |
930 213 40
|
Podest |
1 |
InternKon: 930 204 40 / 17
|
|
|
|
21 |
922 847 40
|
Rail |
1 |
InternKon: 931 122 40 / 15
|
|
|
|
22 |
922 812 40
|
Rail |
1 |
InternKon: 931 122 40 / 16
|
|
|
|
23 |
922 840 40
|
Rail |
2 |
InternKon: 931 027 40 / 1
|
|
|
|
24 |
930 245 40
|
Rail |
2 |
InternKon: 931 027 40 / 2
|
|
|
|
30 |
916 497 40
|
Emergency Ladder |
1 |
InternKon: 930 204 40 / 59
|
|
|
|
31 |
472 511 99
|
Chain |
-2 |
InternBDB: 3-5x18,5 BK | InternKon: 930 204 40 / 55
|
|
|
|
32 |
341 271 99
|
Trigger snap |
2 |
InternBDB: C 70 | InternKon: 930 204 40 / 56
|
|
|
|
33 |
191 538 40
|
Shackle |
2 |
InternBDB: 65 | InternKon: 930 204 40 / 57
|
|
|
|
40 |
946 181 40
|
Emergency jack |
1 |
InternBDB: KF-N5 4901.10.05 / CARLSTAHL | InternKon: 916 740 40 / 1
|
|
|
|
41 |
946 189 40
|
Retainer |
4 |
InternBDB: 20x5x100 | InternKon: 916 740 40 / 5
|
|
|
|
42 |
308 284 99
|
Bolt |
4 |
InternBDB: M5x35 8.8 DIN00931 | InternKon: 916 740 40 / 6
|
|
|
|
43 |
507 036 98
|
Nut |
4 |
InternBDB: M5 DIN00985 | InternKon: 916 740 40 / 7
|
|
|
|
44 |
340 461 99
|
Disc |
4 |
InternBDB: B5,3 DIN00125 | InternKon: 916 740 40 / 8
|
|
|
|
49 |
948 036 40
|
Angle |
1 |
InternKon: 931 027 40 / 13
|
|
|
|
50 |
948 039 40
|
Angle |
1 |
InternKon: 931 027 40 / 3
|
|
|
|
51 |
948 037 40
|
Angle |
1 |
InternKon: 931 027 40 / 4
|
|
|
|
52 |
948 035 40
|
Angle |
1 |
InternKon: 931 027 40 / 5
|
|
|
|
54 |
534 005 99
|
Weld-on plate |
36 |
InternBDB: S-AP-A-3 | InternKon: 931 027 40 / 7
|
|
|
|
56 |
512 545 98
|
Washer |
72 |
InternBDB: A 13 DIN00125 | InternKon: 931 027 40 / 9
|
|
|
|
58 |
930 246 40
|
Plate |
1 |
InternBDB: 144x550 | InternKon: 931 027 40 / 11
|
|
|
|
59 |
308 616 99
|
Bolt |
4 |
InternBDB: M12x140 DIN00931 | InternKon: 931 027 40 / 12
|
|
|
|
60 |
504 004 98
|
Clamp Set |
146 |
InternBDB: S-4-R-38 DIN03015 | InternKon: 930 204 40 / 91
|
|
|
|
61 |
534 008 99
|
Cover plate |
110 |
InternBDB: S-DP-A-4 DIN03015 | InternKon: 930 204 40 / 92
|
|
|
|
62 |
308 615 99
|
Bolt |
170 |
InternBDB: M12x130 DIN00931 | InternKon: 930 204 40 / 93
|
|
|
|
63 |
308 434 99
|
Bolt |
96 |
InternBDB: M12x115 DIN00931 | InternKon: 930 204 40 / 96
|
|
|
|
64 |
509 310 98
|
Locking plate |
80 |
InternBDB: SI-6 | InternKon: 930 204 40 / 97
|
|
|
|
65 |
308 616 99
|
Bolt |
28 |
InternBDB: M12x140 DIN00931 | InternKon: 930 204 40 / 98
|
|
|
|
66 |
334 600 99
|
Nut |
220 |
InternBDB: M12 DIN00985 | InternKon: 930 204 40 / 49
|
|
|
|
67 |
340 467 99
|
Washer |
242 |
InternBDB: B 13 DIN00125 | InternKon: 930 204 40 / 58
|
|
|
|
68 |
938 567 40
|
Plate |
1 |
InternKon: 930 204 40 / 53
|
|
